Handheld Dew Point Meters

Portable Dew Point Meter

Applied portable handheld battery operated Dew point meter model ATS-301D are designed to measures dew point, Moisture and temperature faster and accurately over a wide measurements range . Model ATS-301D is highly optimized to measure the dew point, moisture and Temperature for dryers and compressed air/gases

• Resolution: 0.1 Unit or 1 Unit (Application based)
• Sampling Method: Direct Plug In (optional suction pump)
• Display:  128 X 64 Graphics LCD
• Power Source: Built in Lithium Rechargeable battery
• Accuracy: +/2%
• Response Time: <5 Second
• Data Storage: 5000 or 10000
• Computer Interface: RS 232, USB
• Sensor Life: 2-3 Years
• Operating Time: 6 - 8 hours

Environmental:

• Temperature:-15degree Celsius Humidity :< 85%RH Atmosphere Pressure: 86-   106Kpa
• Housing: High Impact Plastic
• Dimension in mm: 130 (W) X 250 (H) X 90(D)
• Weight: 0.5 KG
• Warranty: One Year
• Specifications:
• Principle:  Thin Film Capacitive
• Range:  Degree C, PPM & % RH
• Resolution: 0.1 Unit or 1 Unit (Application based)
• Sampling Method: Direct Plug In
• Display:  128 X 64 Graphics LCD
• Power Source: Built in Lithium Rechargeable battery
• Accuracy: +/2%
• Response Time: <5 Second
• Data Storage: 5000 or 10000
• Computer Interface: RS 232, USB
• Sensor Life: 2-3 Years
• Operating Time: 6 - 8 hours
• Housing: High Impact Plastic
• Dimension in mm: 130 (W) X 250 (H) X 90(D)
• Weight: 0.5 KG
• Warranty: One Year
