CO2 Gas Analyzer

Name: CO2 Gas Analyzer
Brand: APPLIED TECHNO ENGINEERS PRIVATE LIMITED
Price: 98500.0 INR
Availability: InStock

Price 98500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

CO2 Gas Analyzer Specification

Application
Industrial

Display Type
Graphic

Usage
Industrial

Weight
1.5 Kilograms (kg)

Resolution
0.01%

Product Type
Gas analysis

Accuracy
+2 %

Response Time
10 Seconds

Classification
Ip 65

Power Supply
Electric

Temperature
15 Celsius (oC)

Material
Mild Steel

Humidity
< 85%RH

Dimension (L*W*H)
200 (X 120 X 185 Millimeter (mm)

Machine Weight
20 Kilograms (kg)

Control Mode
Manual

CO2 Gas Analyzer Trade Information

Minimum Order Quantity
1 Number

Supply Ability
40 Per Week

Delivery Time
2 Week

Sample Policy
Within a certain price range free samples are available

Packaging Details
Normal Packing With Thermocol

Main Export Market(s)
Australia, Central America, North America, South America, Eastern Europe, Western Europe, Asia, Middle East, Africa

Main Domestic Market
All India

About CO2 Gas Analyzer

CO2 Gas Analyzer Model ATS-206A

Portable Gas Analyser
We offer comprehensive range of gas Analyzer Portable and Continuous for the analysis of stack/flue gases in exhaust, boiler and combustion process.Model ATS- 206A Flue gas Analyzer measure the flue gases after placing its probe into stack or appliance exhaust and see the concentration of Oxygen (O2), Carbon Monoxide (CO) Carbon Dioxide (CO2) NO2, SO2,NO, NOX etc.

Efficient combustion also reduces emission of pollutants such as nitric oxide (NO), nitrogen dioxide (NO2), sulphur dioxide (SO2), and particulate matter. A gas analyzer will also help measure various gas pollutants in the exhaust for environmental reasons.

Features

Microcontroller based embedded intelligent instruments
Single 320 X 240 Graphics LCD Display
Proven technology from gas analyser experts
ppm or % O2 levels
Hazardous area options
Choice of cells for different applications
Self calibration and self dignostic
Choice of sample systems

Technical Specification

Principle	Electrochemical, Zirconium, Thermal Conductivity and NDIR (Non dispersive Infrared)
Range	%V/V & PPM
Resolution	0.1 Unit or 1 Unit (Application based)
Sampling Method	Auto Suction or Direct Plug In
Gas Sampling Probe	Dia 8mm SS 316
Display	128 X 64 Graphics LCD
Alarm	Visual and Audible
Power Source	Built in Lithium Rechargeable battery
Accuracy	+/2%
Response Time	<5 Second
Data Storage	5000 or 10000
Computer Interface	RS 232, USB, RS485
Sensor Life	4-5 Years
Operating Time	6 - 8 hours
Environmental
Temperature	15degree Celsius
Humidity	< 85%RH
Atmosphere Pressure	86- 106Kpa
Housing	High Impact Plastic
Dimension in mm	200 (W) X 120 (H) X 185(D)
Weight	1.5 KG
Warranty	One Year

High-Precision Measurement

This CO2 Gas Analyzer delivers exceptional accuracy, with a margin of 2%, ensuring that your operational assessments are trustworthy. The precision makes it ideal for industrial sectors where reliable readings are essential, supporting compliance and quality standards. Its advanced sensing technology offers consistent measurements over prolonged use.

Compact and Durable Design

Crafted from robust mild steel, the analyzer combines durability with compactness, measuring only 200 x 120 x 185 mm and weighing just 1.5 kg. Its form factor allows for flexibility, whether in a fixed installation or mobile setup. This sturdy construction ensures optimal protection in demanding industrial conditions.

Versatile Industrial Applications

Engineered for diverse environments, the CO2 Gas Analyzer operates efficiently at 15C and under humidity lower than 85%RH. It supports a wide range of industrial processes, including environmental monitoring, manufacturing quality control, and safety applications, offering versatility for both exporters and service providers in India.

FAQs of CO2 Gas Analyzer:

Q: How does the CO2 Gas Analyzer operate in high-humidity environments?

A: The analyzer is designed to function optimally in environments where the relative humidity is below 85%. Sustained operations above this threshold may affect performance, so it is best used in controlled industrial environments.

Q: What is the process for using this CO2 Gas Analyzer in industrial settings?

A: To use the analyzer, connect it to an electric power supply and place it in the desired monitoring area. Ensure temperatures are around 15C and humidity does not exceed 85%RH. Follow manufacturer guidelines to calibrate and operate the device for precise CO2 measurements.

Q: When should the CO2 Gas Analyzer be calibrated for best results?

A: Calibration should be performed according to the manufacturers recommendations or whenever accuracy is in doubt after prolonged use. Routine calibrations help maintain the 2% accuracy guaranteed by the device.

Q: Where is this CO2 Gas Analyzer manufactured and supplied from?

A: This analyzer is manufactured and supplied from India. The company operates as an exporter, importer, manufacturer, service provider, and supplier, ensuring broad availability across industrial markets.

Q: What are the primary benefits of using this CO2 Gas Analyzer in industrial applications?

A: The main benefits include accurate CO2 monitoring (2% accuracy), robust construction from mild steel, portability due to compact size and light weight, and suitability for a range of industrial conditions, enhancing operational safety and compliance.

Q: How should the device be maintained to ensure long-term reliability?

A: Regular maintenance involves keeping the unit clean, ensuring it is stored and operated within recommended temperature and humidity ranges, and periodic calibration. Adhering to these practices prolongs service life and sustains measurement accuracy.
