Fixed Dew Point Analyzer

Price 158500.0 INR/ Pack

Get a Price/Quote

MOQ : 1 Pack

Fixed Dew Point Analyzer Specification

Temperature Range
15 Celsius (oC)

Application Media
Industrial

Protection
Gas analysis

Humidity %
< 85%RH

Frequency
50 Hertz (HZ)

Resolution
1ppm

Sensor Type
Ec

Usage
Industrial

Material
ABS Plastic

Product Type
Gas analyzer

Accuracy
+/2 %

Display Type
Digital Only

Fixed Dew Point Analyzer Trade Information

Minimum Order Quantity
1 Pack

FOB Port
Mumbai

Supply Ability
5 Packs Per Week

Delivery Time
1 Week

Sample Policy
Within a certain price range free samples are available

Packaging Details
Normal packing with thermocol

Main Export Market(s)
Asia, Australia, North America, Western Europe, Africa, Middle East, Central America, South America, Eastern Europe

Main Domestic Market
All India, South India, Central India, West India, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Goa, Jharkhand, Odisha, Maharashtra, Nagaland, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
An ISO 9001:2015 Company

About Fixed Dew Point Analyzer

Fixed Dew Point Analyzer (Model: ATS-303D)

Owing to our deep-rooted domain expertise, we are bale to manufacture, export and supply high grade Trace Moisture Analyzer. This analyzer is used for measuring the moisture content it finds wide applications in food processing, pharmaceutical and chemical industry. Offered analyzer is manufactured by making use of high grade components with the aid of modern machinery as per market norms. Further, this Trace Moisture Analyzer can be easily availed form us at competitive price range.

Features:-

Remote or integral sensor
fully temp compensated
User friendly design
Optimum performance
Robust construction
Durability

Description :-

Model ATS-303D Process Moisture/ Dew Point Analyzer Designed to Handle Rigorous Demands of Moisture Measurement in Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution for Demanding and Critical Moisture Monitoring Applications.
The advantages of a linear high capacitance response are: better sensitivity, better repeatability and faster response times. Also, the measurement system is less prone to noise and drift, and signal conditioning is kept to a minimum.
The dew point meter is operated through a menu driven user interface consisting of a custom LCD display with backlight, and four push buttons.
This dew point system has proven to produce consistently accurate monitoring results for dew point in natural gas and other difficult hydrocarbon processing applications, where conventional analyzers have failed.

Specification :-

Principle	Thin Film Capacitive, Capacitive Aluminium Oxide
Range	Degree C, PPM & % RH
Resolution	0.1 Unit or 1 Unit (Application based)
Sampling Method	Direct Plug In
Display	128 X 64 Graphics LCD
Power Source	Built in Lithium Rechargeable battery Or 230V AC
Accuracy	+/2%
Response Time	<5 Second
Data Storage	5000 or 10000
Computer Interface	RS 232, USB
Anolog Output	4-20mA
Sensor Life	2-3 Years
Operating Time	6-8 hours
Environmental
Temperature	15degree Celsius
Humidity	< 85%RH
Atmosphere Pressure	86-106Kpa
Housing	High Impact Plastic
Dimension in mm	200 (W) X 120 (H) X 185(D)
Weight	1.5 KG
Warranty	One Year

Robust and Accurate Measurement

Engineered for industrial applications, this dew point analyzer provides highly accurate readings in environments where maintaining optimal moisture levels is critical. Its digital display enables clear and immediate data interpretation, streamlining monitoring processes and supporting quality control.

Industrial-Grade Construction

Manufactured from sturdy ABS plastic, the analyzer withstands harsh industrial conditions while delivering reliable operation. Its fixed installation means minimal manual handling, reducing wear and supporting longevity even under frequent use.

Comprehensive Industry Support

We serve as exporter, importer, manufacturer, service provider, and supplier, offering end-to-end assistance, from product selection and installation to after-sales servicing and technical support, ensuring you optimize your moisture measurement investments.

FAQs of Fixed Dew Point Analyzer:

Q: How does the Fixed Dew Point Analyzer function in industrial environments?

A: The analyzer continuously monitors the dew point using advanced sensors and displays real-time readings digitally. Its robust design allows it to operate reliably within a 15C temperature range and up to 85% relative humidity, ensuring precise moisture control for industrial processes.

Q: What are the main benefits of using this digital-only dew point analyzer?

A: This analyzer provides accurate, easy-to-read results, with 2% accuracy, crucial for maintaining process standards. Its digital display eliminates misinterpretations, streamlining diagnostics, minimizing downtime, and enhancing overall operational efficiency.

Q: When should the Fixed Dew Point Analyzer be used?

A: It should be employed whenever continuous and accurate monitoring of moisture levels is essential, such as in manufacturing, storage facilities, or any process where controlling humidity and dew point is vital to product quality or equipment longevity.

Q: Where can this analyzer be installed within an industrial setup?

A: The device is designed for fixed installation on-site, making it ideal for locations where constant monitoring is required. Its durable ABS plastic construction allows it to withstand various industrial environments in India and abroad.

Q: What is the process for integrating this analyzer into an existing system?

A: Integration involves mounting the analyzer at the designated monitoring point and connecting it to the power supply (50Hz). Upon installation, calibration is performed according to usage requirements, and the analyzer is set for continuous digital monitoring.

Q: How is the analyzer maintained to ensure consistent accuracy?

A: Routine checks include verifying sensor calibration and inspecting the unit for any wear. As a service provider, we offer scheduled maintenance and technical support to uphold the analyzers accuracy and operational integrity.
