Online tri gas analyzer

About Online tri gas analyzer

The Online Tri Gas Analyzer Model ATS-208A is a high-precision industrial gas analyzer designed for continuous monitoring of three key gases in process and turbine applications. It enables accurate real-time measurement of gases such as hydrogen (H), carbon dioxide (CO), and oxygen (O) using advanced thermal conductivity, NDIR, and electrochemical sensing technologies. Engineered for online fixed installation, the analyzer provides fast response (T90 < 10 seconds), high accuracy (1% FS), and stable long-term performance. With its integrated sample conditioning system, flameproof design, and digital communication interfaces, it is ideal for hydrogen purity monitoring, generator safety, and industrial process control.

Key Features Online Tri Gas Analyzer

• Continuous online monitoring of three critical gases
• Accurate measurement of H, CO, and O
• Thermal conductivity (TCD) sensor for hydrogen analysis
• NDIR sensor for CO measurement
• Electrochemical/paramagnetic sensor for oxygen detection
• Fast response time (T90 < 10 seconds) for real-time analysis
• Fully automatic operation with self-diagnostic system
• Flameproof / explosion-proof design (Zone 1 suitable)
• Integrated sampling system with filtration and moisture removal
• Inbuilt suction pump for reliable gas sampling
• High-resolution 320 240 graphics LCD display
• Multiple outputs: 420 mA, RS232, RS485, Modbus RTU
• Programmable alarms with visual and audible alerts
• Auto calibration feature for consistent accuracy

Basic Specifications Online Tri Gas Analyzer

• Model: ATS-208A
• Type: Online / Fixed Tri Gas Analyzer
• Gases Measured: H, CO, O (configurable)
• Measurement Principle: Thermal Conductivity (TCD), NDIR, Electrochemical / Paramagnetic
• Measurement Range: Up to 0100% (depending on gas)
• Resolution: 0.01%
• Accuracy: 1% of full scale
• Repeatability: 0.5% FS
• Response Time: <10 seconds (T90)
• Display: 320 240 Graphics LCD
• Power Supply: 230 VAC / 24 VDC
• Outputs: 420 mA, RS232, RS485, Modbus RTU
• Sampling System: Complete system with SS316 tubing, filters, moisture removal & flow control
• Operating Temperature: -20C to +60C
• Safety: Flameproof / Explosion-proof (Zone 1 certified)
