Portable Gas Leak Detector With Pump
Portable Gas Leak Detector With Pump
Portable Gas Leak Detector With Pump
Portable Gas Leak Detector With Pump
Portable Gas Leak Detector With Pump
Portable Gas Leak Detector With Pump
Portable Gas Leak Detector With Pump
Portable Gas Leak Detector With Pump

Portable Gas Leak Detector With Pump

Price 44000.0 INR/ Unit

MOQ : 1 Unit

Portable Gas Leak Detector With Pump Specification

  • Automation Grade
  • Semi-automatic
  • Operating Voltage
  • 3.7V rechargeable battery
  • Test Range
  • Oxygen: 0-30% Vol. (Default, other gases available)
  • Display Type
  • Large Backlit Digital LCD Display
  • Port Size
  • Standard probe inlet 5-8mm
  • Features
  • Built-in buzzer, alarm indicators, data retention, pump-enabled sampling
  • Equipment Type
  • Portable Gas Leak Detector With Pump
  • Temperature
  • -10C to 50C
  • Accuracy
  • 1% of reading
  • Response Time
  • <10 seconds
  • Measuring Range
  • 0-30% Vol. (O2), sensors available for other gases
  • Gas Pressure
  • Ambient atmospheric pressure
  • Application
  • Industrial safety, confined space entry, laboratory, storage monitoring
  • Hardness
  • ABS plastic casing
  • Power Supply
  • Rechargeable Lithium-ion battery / USB Powered
  • Humidity
  • 0-95% RH (non-condensing)
  • Interface Type
  • Membrane keypad, USB charging port
  • Resolution
  • 0.1% (for O2), varies by gas sensor
  • Number of Specimens
  • Single Zone or Point Measurement
  • Mounting Type
  • Handheld
  • Usage
  • Portable detection of gas leaks in various environments
  • Capacity
  • Handheld Portable
  • Machine Weight
  • Approx. 300g (with battery)
  • Test Speed
  • Adjustable (Pump speed variable)
  • Control Mode
  • Manual & Automatic power ON/OFF
  • Sensor Type
  • Electrochemical (O2) / Custom for other gases
  • Battery Life
  • 5-8 hours continuous operation
  • Enclosure Rating
  • IP54 (splash proof)
  • Data Logging
  • Optional (custom variants)
  • Dimensions
  • Approx. 160 x 85 x 40 mm
  • Alarm Type
  • Audio-visual (Buzzer + LED)
  • Calibration
  • User-calibratable, factory calibration available
  • Pump Type
  • Integrated micro diaphragm pump



About Portable Gas Leak Detector With Pump

The Handheld Single Gas Detector With Pump is a compact and portable gas detection instrument designed for reliable monitoring of a specific gas in industrial, hazardous and confined-space environments. The integrated sampling pump enables active gas sampling from locations that are difficult to access, providing convenient and reliable detection of oxygen, toxic, combustible and other hazardous gases. Available in different gas configurations, the detector is suitable for personal safety, gas leak detection, confined-space entry, process monitoring and routine workplace gas monitoring. Its rugged handheld design makes it suitable for applications across oil & gas, oil refineries, petrochemical, chemical, pharmaceutical, fertilizer, power plants, steel, mining, battery manufacturing and other industrial sectors. The detector provides clear gas concentration readings along with visual and audible alarms when preset gas levels are reached, making it suitable for a wide range of industrial gas detection and safety applications.

Advanced Gas Detection for Versatile Safety Applications

Experience reliable, on-the-go gas monitoring with this portable detector, suitable for industrial safety, laboratory analysis, storage area monitoring, and confined space entry. Its lightweight, handheld design allows for easy operation in diverse work settings, delivering results within 10 seconds. The IP54 splash-proof rating and tough ABS plastic casing ensure long service life even in challenging environments. Custom sensor options extend usability for various gases, making it an indispensable tool for professionals.


Intuitive Operation with Customizable Features

Control the device effortlessly using its membrane keypad and large, backlit LCD display. Automatic and manual power modes adapt to your workflow, while variable pump speed facilitates accurate sampling. The integrated buzzer and LED indicators provide clear, unmistakable alerts in hazardous situations. Easy-to-use calibration ensures ongoing accuracy, and optional data logging supports comprehensive safety documentation tailored for your operation.

FAQ's of Portable Gas Leak Detector With Pump:


Q: How does the integrated pump enhance gas leak detection efficiency?

A: The built-in micro diaphragm pump actively draws air samples into the sensor at adjustable speeds, ensuring rapid and reliable detection of toxic or flammable gases. This feature makes it especially useful for sampling hard-to-reach or confined areas where precise monitoring is critical.

Q: What types of gases can be detected with this portable device?

A: The standard sensor detects oxygen (O2) within a 0-30% volume range. However, custom sensors are available to accommodate the detection of other gases such as CO, H2S, or specific industrial gases, making the detector adaptable for various monitoring needs.

Q: When should the device be calibrated, and what options are available?

A: Calibration should be performed regularly as per industry guidelines or whenever sensor readings appear inconsistent. The unit supports user calibration for convenience, but factory calibration is also available for assured accuracy and compliance.

Q: Where can this portable gas leak detector be used effectively?

A: Its splash-proof, durable design makes it ideal for use in industrial facilities, confined spaces, laboratories, and storage environments where portable leak detection is required. The handheld form factor and rechargeable battery offer excellent mobility and flexibility.

Q: What is the process for logging and retrieving data on this device?

A: Optional variants provide data logging capabilities, allowing you to store and later retrieve measurement records. Data can be accessed through the device's interface or via USB connection for further analysis and documentation.

Q: How long does the battery last during continuous operation, and how is it recharged?

A: The rechargeable lithium-ion battery supports 5-8 hours of continuous use. Recharging is simple using the supplied USB charging port, ensuring minimal downtime between uses.

Q: What benefits does the audio-visual alarm system provide?

A: The built-in buzzer and LED indicators deliver immediate, clear warnings in the event of gas detection above set thresholds, significantly enhancing site safety by alerting users to potential hazards quickly and effectively, even in noisy or visually impaired environments.
