Portable gas purity analyzer

Name: Portable gas purity analyzer
Brand: APPLIED TECHNO ENGINEERS PRIVATE LIMITED
Price: 240000.0 INR
Availability: InStock

Price 240000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Portable gas purity analyzer Specification

Gas Pressure
0.1~0.3 MPa

Specimen Size
N/A (gas sampling)

Port Size
1/8 NPT

Number of Specimens
Single sample analysis per cycle

Accuracy
1% of full scale

Interface Type
USB, RS232

Response Time
10 seconds

Features
Compact, lightweight, rechargeable, real-time digital display, audible alarm

Mounting Type
Handheld (portable)

Application
Industrial gas testing, Laboratory analysis

Automation Grade
Semi-automatic

Test Range
0-100% purity (typical for O2, N2, H2, Ar, CO2, He)

Equipment Type
Portable gas purity analyzer

Operating Voltage
3.7V DC (battery) / 220V AC

Frequency
50 Hz

Display Type
LCD digital display

Humidity
0-95 %RH (non-condensing)

Max Height
220 mm

Power Supply
Rechargeable Li-ion battery / AC 220V, 50Hz

Resolution
0.01%

Measuring Range
Multiple sensor options: 0-100% (specific to gas type)

Temperature
0 to 45C (operating)

Usage
Onsite and field gas purity measurement

Capacity
Continuous gas flow or sample injection

Machine Weight
2.5 kg

Test Speed
Quick analysis (<10 seconds response time)

Control Mode
Manual and automatic selectable

Alarm Function
Visual and audible alarm for low/high purity threshold

Calibration
User-friendly calibration with standard reference gases

Protection Class
IP54 (dust and splash resistant)

Enclosure Material
ABS engineering plastic

Battery Backup
8 hours continuous operation

Sampling Method
Direct gas sampling with replaceable inlet filter

Sensor Type
Electrochemical / Thermal conductivity / Zirconia (as per gas measured)

Data Logging
Built-in memory for up to 1000 test results

About Portable gas purity analyzer

The Portable Gas Purity Analyzer is a compact and high-precision device designed for on-site measurement of gas purity across various industrial applications. It is widely used in gas plants, refineries, chemical industries, pharmaceutical units, and laboratories where mobility and quick testing are essential.

This portable analyzer measures the purity of gases such as Hydrogen (H), Oxygen (O), Nitrogen (N), Argon (Ar), and other specialty gases. It provides fast and accurate real-time readings, helping industries ensure gas quality, detect impurities, and maintain process efficiency.

Equipped with advanced sensor technologies like Thermal Conductivity Detection (TCD), Electrochemical, or Paramagnetic sensors (depending on gas type), the analyzer ensures reliable and stable performance. Its lightweight design, rechargeable battery, and easy-to-use interface make it ideal for field applications.

With rugged construction and low maintenance requirements, the Portable Gas Purity Analyzer is the perfect solution for quick, efficient, and accurate gas purity analysis on the go.

Key Features:

Portable and lightweight design for field use
Accurate gas purity measurement
Suitable for multiple gases (H, O, N, Ar, etc.)
Fast response with real-time readings
Advanced sensor technology (TCD / Electrochemical / Paramagnetic)
Rechargeable battery operation
User-friendly digital display
Durable and rugged construction
Low maintenance and long service life

Basic Specifications:

Gases Measured: H, O, N, Ar (or as required)
Measurement Range: 0100% purity
Sensor Technology: TCD / Electrochemical / Paramagnetic
Accuracy: 1% FS or better
Display: LCD / Digital Display
Power Supply: Rechargeable Battery
Battery Backup: 610 hours (approx.)
Response Time: < 1530 seconds
Portability: Handheld / Portable Unit
Operating Temperature: 0C to 50C
Application: Field Testing, Gas Plants, Refineries, Laboratories, Industrial Sites

Versatile and Reliable Measurement

This portable analyzer provides accurate purity readings for a variety of gases with rapid test speeds, typically delivering results in less than 10 seconds. Multiple selectable sensors allow flexibility according to the specific gas measured, making the device highly adaptable for laboratories and industrial sites.

Intuitive Operation with Enhanced Safety

Its user-friendly calibration interface, supported by standard reference gases, ensures straightforward maintenance. The analyzer's visual and audible alarms instantly alert users when gas purity thresholds are breached, promoting safety and operational continuity.

Designed for On-the-Go Professionals

Compact and weighing only 2.5 kg, the analyzer is housed in a durable ABS enclosure with IP54 protection against dust and splashes. It supports both battery and AC power, features a handheld design for portability, and offers robust data storage with USB and RS232 connectivity for easy data management.

FAQ's of Portable gas purity analyzer:

Q: How does the portable gas purity analyzer perform direct gas sampling?

A: The analyzer utilizes a direct gas sampling method with a replaceable inlet filter. This design allows users to draw gas samples quickly and efficiently, ensuring accurate readings by minimizing contamination from particulates.

Q: What is the calibration process for this analyzer and how user-friendly is it?

A: Calibration is performed using standard reference gases. The interface is designed for simplicity, guiding users step-by-step through the calibration process to maintain measurement accuracy without requiring extensive technical expertise.

Q: Where can this gas purity analyzer be effectively used?

A: The device is suitable for both industrial and laboratory environments, including field testing, production plants, quality control labs, and on-site inspections, making it ideal for exporters, importers, manufacturers, service providers, and suppliers across India.

Q: What is the benefit of the analyzer's alarm function?

A: The visual and audible alarms provide immediate notification if detected purity falls outside preset thresholds. This feature helps users quickly respond to abnormal conditions, protecting equipment, processes, and safety.

Q: How is data stored and accessed from the device?

A: The analyzer includes built-in memory capable of storing up to 1000 test results. Data can be easily transferred and managed via USB or RS232 interfaces for detailed analysis and reporting.

Q: Can the analyzer operate for long periods without external power?

A: Yes, its rechargeable lithium-ion battery offers up to 8 hours of continuous use. For extended sessions, the analyzer also operates on AC 220V, 50Hz mains power, ensuring flexibility in diverse environments.

Q: What gases can the analyzer measure and what is its range and accuracy?

A: Depending on its sensor configuration, the analyzer accurately measures gases including oxygen, nitrogen, hydrogen, argon, carbon dioxide, and helium, with a measuring range of 0-100% purity, 1% full-scale accuracy, and a resolution of 0.01%.
