Portable Turbind gas analyser

About Portable Turbind gas analyser

The Continuous Process Gas Analyzer Model ATS-208A is an advanced online gas analysis system designed for uninterrupted monitoring of industrial process gases with high accuracy and reliability. It continuously measures gases such as hydrogen (H), carbon monoxide (CO), carbon dioxide (CO), oxygen (O), nitrogen (N), and methane (CH) using proven thermal conductivity, NDIR, and electrochemical sensing technologies. Built for 24/7 operation in harsh and hazardous environments, the analyzer delivers fast response (T90 < 10 seconds), 1% accuracy, and stable long-term performance. With a flameproof design, integrated sample conditioning system, and digital communication outputs, it is ideal for process optimization, safety monitoring, and regulatory compliance across industries.

Key Features Continuous Process Gas Analyzer

• 24/7 continuous monitoring of process gas composition
• Simultaneous multi-gas analysis (H, CO, CO, O, N, CH)
• High-precision thermal conductivity (TCD) sensor for hydrogen
• NDIR sensors for CO, CO, and CH detection
• Electrochemical/paramagnetic sensor for oxygen (O)
• Fast response time (T90 < 10 seconds) for real-time process control
• Fully automatic operation with self-diagnostic system
• Flameproof / explosion-proof design (Zone 1 certified)
• Integrated sample conditioning system (filters, moisture removal, flow control)
• Inbuilt suction pump ensures consistent sampling
• 320 240 graphics LCD with continuous digital readout
• Outputs: 420 mA, RS232, RS485, Modbus RTU
• Programmable alarms with visual and audible alerts
• Auto calibration for reliable long-term accuracy

Basic Specifications Continuous Process Gas Analyzer

• Model: ATS-208A
• Type: Online / Continuous Gas Analyzer
• Gases Measured: H, CO, CO, O, N, CH (configurable)
• Measurement Principle: Thermal Conductivity (TCD), NDIR, Electrochemical / Paramagnetic
• Measurement Range: Up to 0100% (gas dependent)
• Resolution: 0.01%
• Accuracy: 1% of full scale
• Repeatability: 0.5% FS
• Response Time: <10 seconds (T90)
• Warm-up Time: ~1 minute
• Display: 320 240 Graphics LCD
• Power Supply: 230 VAC / 24 VDC
• Outputs: 420 mA, RS232, RS485, Modbus RTU
• Sampling System: SS316-based system with filtration, moisture removal & flow control
• Operating Temperature: -20C to +60C
• Safety: Flameproof / Explosion-proof (CIMFR / PESO, Zone 1)
