ATS-203A Hydrogen Purity Analyser

About ATS-203A Hydrogen Purity Analyser

The Hydrogen Purity Analyzer Model ATS-203A is a high-precision portable gas analyzer designed for accurate measurement of hydrogen purity in industrial applications. Based on advanced thermal conductivity (TCD) technology, it enables reliable monitoring of H in air and H in CO, making it ideal for hydrogen-cooled generators and turbine systems. The analyzer provides fast response, high accuracy, and long-term stability with a non-consumable sensor. Its portable design, inbuilt sampling system, and rechargeable battery ensure convenient field operation, making it perfect for purging processes, maintenance, and safety monitoring.

Key Features Hydrogen Purity Analyzer

• Accurate hydrogen purity measurement using TCD sensor
• Tri-gas analysis: H in Air, H in CO, CO in Air
• Fast response time (1015 seconds) for real-time readings
• Portable and lightweight design (1.5 kg)
• Long-life, non-consumable sensor (>10 years)
• Intrinsically safe for industrial applications
• Rechargeable lithium battery with up to 8 hours backup
• Inbuilt suction pump with sampling system
• 128 64 LCD display for clear readings
• USB / RS232 communication interface
• Microcontroller-based intelligent operation
• Low maintenance and reliable performance

Basic Specifications Hydrogen Purity Analyzer

• Model: ATS-203A
• Type: Portable Hydrogen Purity Analyzer
• Measurement Principle: Thermal Conductivity (TCD)
• Measurement Ranges:
  • 0100% H in Air
  • 0100% H in CO
  • 0100% CO in Air
• Resolution: 0.1%
• Accuracy: 1% FS (0.5% for H in Air)
• Response Time: 1015 seconds (T90)
• Display: 128 64 LCD
• Power Supply: Rechargeable battery / 230V AC adapter
• Operating Temperature: 0C to 50C
• Weight: 1.5 kg
• Sampling: Inbuilt pump with conditioning filter
