Biogas Analyzer

Name: Biogas Analyzer
Brand: APPLIED TECHNO ENGINEERS PRIVATE LIMITED
Price: 248500.0 INR
Availability: InStock

Price 248500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Biogas Analyzer Specification

Response Time
10 Seconds

Display Type
LCD digital display

Product Type
Gas analysis

Equipment Type
Biogas Analyzer

Test Range
0-100%

Gas Pressure
0.1-0.6 MPa mpa

Classification
IP 65

Humidity
<90%RH

Temperature
-10 C to 50 C Celsius (oC)

Mounting Type
Tabletop/Portable

Measuring Range
CH4 0-100%, CO2 0-100%, H2S 0-5000 ppm, O2 0-25%, NH3 0-1000 ppm Kelvin (K)

Frequency
50Hz Hertz (HZ)

Automation Grade
Automatic

Interface Type
RS232/RS485, USB

Operating Voltage
220V Volt (V)

Power Supply
AC 220V 10%, 50Hz

Port Size
6 mm

Application
Biogas, landfill gas, digester gas analysis

Resolution
0.01% (for CH4/CO2/O2), 1 ppm (for H2S/NH3)

Features
Data logging, alarm system, multi-gas real-time monitoring

Usage
Biogas content detection

Capacity
5 gases simultaneous detection Pcs/hr

Machine Weight
3 Kilograms (kg)

Control Mode
Manual

Sensor Type
Electrochemical/Infrared

Sampling Method
Manual/automatic sampling

Battery Backup
Up to 8 hours

Alarm Type
Visual and audible

Data Storage Capacity
10000 readings

Biogas Analyzer Trade Information

Minimum Order Quantity
1 Number

FOB Port
Mumbai

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
50 Per Week

Delivery Time
1 Week

Sample Policy
Within a certain price range free samples are available

Packaging Details
Normal Packing with thermocol

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Biogas Analyzer

Biogas Analyzer Model : ATS-206A

With timely upgrading our machinery, we are capable to offer our clients high grade Biogas Analyzer for our valuable clients. This analyzer is used for detecting the level of bio gas and it finds wide applications in steel, beverage, oil gas and other industry. The offered analyzer is manufactured by utilizing pristine quality components with the aid of cutting-edge tools and technology as per market norms. Available in several technical specifications, this Biogas Analyzer can be purchased from us at reasonable prices.

Features:

Sturdy construction
Low power consumption
Noise free operations
Longer service life
complete automatic operation & Self diagnostic check.

Description :-

Model ATS-202A is single of Multigas Portable Instrument for Bio Gas and process gas Analysis for various industries. Landfill gas and Bio gas is produced by the bio-degradation of waste. Landfill gas is produced from general waste buried in the ground; and bio-gas from plant and animal waste products contained in a sealed digester tank.
Both gases comprise mainly methane (CH4) and carbon dioxide (CO2). The methane component is either burnt as a fuel or flared off as waste.
Our landfill gas / Bio gas analyzers maximize the extraction of energy and ensure it is safe to burn without - (the problem occurs if air, i.e. oxygen, infiltrates the gas).
Our Application specific Portable Gas Analyzers provides continuous process analysis of the following Gases.
Oxygen (O2), Carbon Monoxide (CO), Carbon dioxide (CO2), Sulphur Dioxide (SO2), Nitric Oxide (NO),Nitrogen Dioxide (NO2), Nitrous Oxide(N2O), Hydrogen (H2), Hydrogen Sulphide ( H2S) and Hydrocarbons.

Specifications
Principle	Electrochemical and NDIR
Range	%V/V & PPM
Resolution	0.1 Unit or 1 Unit (Application based)
Sampling Method	Auto Suction or Direct Plug In
Display	128 X 64 Graphics LCD
Alarm; Two Levels Low & High,	Visual and Audible
Power Source	Built in Lithium Rechargeable battery
Accuracy	+/2%
Response Time	<5 Second
Data Storage	5000 or 10000
Computer Interface	RS 232, USB, RS485
Sensor Life	2-3 Years
Operating Time	6 8 hours
Environmental
Temperature	15degree Celsius
Humidity	< 85%RH
Atmosphere Pressure	86- 106Kpa
Housing	High Impact Plastic
Dimension in mm	200 (W) X 120 (H) X 185(D)
Weight	1.5 KG
Warranty	One Year

Versatile and Reliable Gas Detection

This Biogas Analyzer ensures accurate, real-time monitoring of multiple gas components crucial for biogas applications. Its robust sensor technology and automated sampling enhance both safety and efficiency in environments such as landfills and digesters. With capabilities like data storage, alarm systems, and a user-friendly LCD display, it streamlines compliance and operational workflow for biogas professionals.

Flexible Sampling and Portable Design

Offering both manual and automatic sampling methods, this analyzer adapts to different operational needs. Compact in size and equipped with a long-lasting battery backup, it supports tabletop and portable use, making it ideal for on-site and laboratory applications. Its sturdy build and intuitive interface ensure ease of use across diverse working conditions.

FAQ's of Biogas Analyzer:

Q: How does the Biogas Analyzer detect and measure multiple gases simultaneously?

A: The Biogas Analyzer utilizes a combination of electrochemical and infrared sensors to continuously detect up to five gases-CH4, CO2, O2, H2S, and NH3. These sensors provide real-time, accurate readings displayed on the LCD screen, ensuring comprehensive gas analysis in a single operation.

Q: What is the typical process for sampling with this analyzer?

A: The analyzer offers both manual and automatic sampling options. Users can manually collect samples or rely on the automatic system, which streamlines analysis and minimizes potential for human error. This flexibility allows adaptation to varied site conditions and user preferences.

Q: When should I use the visual and audible alarm features?

A: Visual and audible alarms are triggered automatically when gas concentrations exceed pre-set safety thresholds. This immediate warning system helps ensure prompt action, protecting personnel and maintaining safe operational environments during gas measurement tasks.

Q: Where can the Biogas Analyzer be used most effectively?

A: It is ideal for biogas plants, landfills, and anaerobic digesters where multi-gas analysis is critical. The portable and compact design allows deployment both in-field and in laboratory settings, supporting a wide range of biogas monitoring applications.

Q: What benefits does data logging provide in this analyzer?

A: With a storage capacity of up to 10,000 readings, the analyzer's data logging function enables comprehensive tracking and analysis over time. This feature supports compliance, trend analysis, and process optimization by providing easy data retrieval through USB or RS232/RS485 interfaces.

Q: How accurate and reliable is the Biogas Analyzer under varying conditions?

A: Engineered to operate in temperatures from -10C to 50C and humidity levels below 90% RH, the analyzer maintains an accuracy of 2%. Its robust design ensures consistent results in diverse and challenging industrial environments.
