Broken Bag Detector

Price 58000 INR/ Set

Get a Price/Quote

MOQ : 1 Set

Broken Bag Detector Specification

Temperature
15 Celsius (oC)

Accuracy
+2 %

Usage
Industrial

Humidity
< 85%RH

Power Supply
Electric

Color
White

Broken Bag Detector Trade Information

Minimum Order Quantity
1 Set

Supply Ability
40 Sets Per Week

Delivery Time
2-3 Week

Sample Policy
Within a certain price range free samples are available

Packaging Details
Normal Packing With Thermocol

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Broken Bag Detector

Description :-

A Dust particulate monitor is a device that is mounted in the discharge stack of a dust collector and continuously monitors the amount of particulate discharge. The particulate monitor uses a technology known as Triboelectric or Triboelectricity.
When two different materials come in contact, it is likely that one will leave with more electrons than it started with and the other will leave with less, this is called Triboelectric Effect. The interaction between the probe and particles produces a charge transfer within the probe. The charge is then converted to an output signal.
The advanced electronics of the Monitor detect this signal and present it to the operator via a modulating Graphical display.

Specification :-

Emissions (Dust Monitoring/Maintenance)

Turboelectric particulate matter measurement technology is proven to be the most reliable and cost effective, and sometime the only practical technology for particle flow monitoring.

Dust Monitor Model ATS-402P suite of turboelectric products is used by heavy industry to:

Create early-warning leak detection systems and avert major disasters in operations that use dust collector filter bags
Monitor, record, and track particle emissions for regulatory compliance
Optimize the dust collector maintenance schedule and production process

Process

Applied monitoring equipment improves process efficiency for higher financial return

Provides reliable Flow or No Flow indications for many process applications such as:

Powder injection
Pneumatic conveying
Screw conveyor flow, etc.

Range	:	0-1000 Mg/M3
Sensor	:	Base Systems Style Integral Remote
Remote Sensor Enclosure:	:	Cost Aluminium, Electrostatically powder coating
Probe Material:	:	316 Stainless Steel (Slandered) other materials available
Insulator material:	:	Extended High Performance (PFA) Temperature up to 250 C Ceramic (High temperature up to 550 Deg C )
Electronics	:	18 32 V DC () at the unit 230V AC (Controller)
Output:	:	4-20mA & SPDT Relay
Probe Insertion length:	:	3 to 36 ( 7.6 Cm to 91.4 Cm)
Installation	:	Weld the supplied fitting into the pipe or Duct and insert Sensor
Sensor Mounting	:	Flanged Male NPT Quick release

Range	0-1000 Mg/M3
Sensor	Base Systems Style Integral Remote
Remote Sensor Enclosure:	Cost Aluminium, Electrostatically powder coating
Probe Material:	316 Stainless Steel (Slandered) other materials available
Insulator material:	Extended High Performance (PFA) Temperature up to 250 C Ceramic (High temperature up to 550 Deg C )
Electronics	18 - 32 V DC () at the unit 230V AC (Controller)
Output:	4-20mA & SPDT Relay
Probe Insertion length:	3 to 36 ( 7.6 Cm to 91.4 Cm)
Installation	Weld the supplied fitting into the pipe or Duct and insert Sensor
Sensor Mounting	Flanged Male NPT Quick release

Reliable Filter Monitoring

The Broken Bag Detector ensures early detection of filter bag failures in dust collection systems. By continuously monitoring air quality and particle presence, it safeguards both industrial equipment and workplace environment. With high accuracy and stability, this device helps companies avoid costly downtime and maintain clean operations.

Precision Accuracy and Robust Performance

Built with an accuracy of 2%, the detector consistently delivers reliable results even in varying humidity conditions (below 85% RH). Operating seamlessly at 15C, its ideal for a range of industrial applications, helping businesses adhere to strict safety and environmental regulations.

FAQs of Broken Bag Detector:

Q: How does the Broken Bag Detector function in industrial settings?

A: The Broken Bag Detector continuously monitors the air within dust collection systems. When a filter bag fails, it detects an increase in particle emissions and instantly triggers an alert, allowing operators to take immediate corrective action.

Q: What is the benefit of using this detector in factories or plants?

A: Using this device minimizes dust leakage, preventing damage to equipment and maintaining cleaner air within the facility. It also supports compliance with environmental safety standards, reducing the risk of fines and production stoppages.

Q: When should the Broken Bag Detector be installed in a dust collection system?

A: It is best to install the detector during the initial setup of your filtration system or during regular maintenance to ensure continuous and reliable monitoring.

Q: Where can this detector be used effectively?

A: This product is suitable for a variety of industrial environments, such as manufacturing, cement, pharmaceuticals, and food processing plantsanywhere filtration systems are critical to operations.

Q: What process does the detector use to notify users of a bag failure?

A: Upon detecting an abnormal level of particles in the airflow (indicating possible filter breach), the detector sends an electrical signal or alarm to notify staff immediately, enabling prompt action.

Q: How is the device powered and what are its environmental limits?

A: The detector is powered by electricity and is designed to deliver reliable performance at a temperature of 15C and in environments where humidity remains below 85% RH.
