CO,Industrial CO Gas Transmitter

Name: CO,Industrial CO Gas Transmitter
Brand: APPLIED TECHNO ENGINEERS PRIVATE LIMITED
Price: 175000.0 INR
Availability: InStock

Price 175000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

CO,Industrial CO Gas Transmitter Specification

Humidity
15% to 95% RH (non-condensing)

Specimen Size
N/A (Direct air sampling)

Accuracy
3% F.S.

Temperature
Working: -20C to +50C

Number of Specimens
Single point sensing

Test Range
0-1000 ppm

Sensor
Electrochemical CO Sensor

Test Material
Carbon Monoxide Gas

Display
Digital LCD Display

Operating Temperature
-20C to +50C

Response Time
30 seconds (T90)

Power Supply
DC 24V (External)

Gas Pressure
Atmospheric / 90-110 kPa

Type
CO Gas Transmitter

Use
Industrial Carbon Monoxide Detection

Test Medium
Air (CO Gas Detection)

Operating Voltage
DC 24V

Shell Material
ABS Plastic & Aluminum Alloy

Net Weight
Approx. 350g

Pedestal Size
Compact Industrial Mount

Port Size
Standard (Customizable as per requirement)

Operating Mode
Continuous Monitoring

Calibration
Manual/automatic calibration supported

Warm-up Time
2 minutes

Ingress Protection
IP65

Signal Output
4-20mA / RS485 / Relay (optional)

Working Environment
Industrial and hazardous gas environments

Service Life (Sensor)
2-3 years typical

Storage Temperature
-30C to +60C

Alarm Function
Visual & Audible Alarm

Dimensions
125 85 55 mm (approx.)

Installation
Wall Mounted

CO,Industrial CO Gas Transmitter Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
7 Days

About CO,Industrial CO Gas Transmitter

CO / Industrial Carbon Monoxide Gas Transmitter

The Industrial CO Gas Transmitter is a high-performance device designed for continuous monitoring of Carbon Monoxide (CO) levels in industrial environments. It ensures accurate detection of toxic CO gas to enhance workplace safety, prevent hazardous exposure, and maintain regulatory compliance.

Built with advanced electrochemical sensor technology, the transmitter provides precise real-time measurement with fast response time and excellent long-term stability. It is highly sensitive to low-level CO concentrations, making it ideal for critical safety applications.

The device supports industry-standard 420mA output along with optional digital communication (RS485/Modbus), enabling seamless integration with PLC, SCADA, and DCS systems for continuous monitoring and control.

Its rugged, weatherproof, and explosion-proof design ensures reliable performance in harsh and hazardous industrial conditions. Easy installation, low maintenance, and long service life make it a dependable solution for industrial gas monitoring.

Key Features:
Accurate and continuous CO gas monitoring
High sensitivity for low-level detection
Fast response with stable performance
420mA output with optional RS485/Modbus
Suitable for industrial safety applications
Rugged, explosion-proof industrial design
Low maintenance and long sensor life

Reliable CO Detection for Industrial Safety

This CO Gas Transmitter provides continuous, real-time monitoring of carbon monoxide levels, essential for industrial environments where gas exposure risk exists. Its compact design, robust housing, and IP65 rating ensure it withstands demanding conditions. The digital display gives instant readings, while visual and audible alarms notify personnel immediately if thresholds are exceeded. Easy wall mounting and customizable port sizes allow integration into various facilities, enhancing workplace safety.

Advanced Features and Flexible Output Options

Equipped with selectable outputs (4-20mA, RS485, and optional relay), this transmitter suits diverse control systems. It supports both manual and automatic calibrations to maintain high accuracy, with a fast 30-second response time (T90). The electrochemical sensor ensures precise detection across a range of 0-1000 ppm. Designed for atmospheric pressures and wide humidity, it works reliably, ensuring smooth industrial operations.

FAQ's of CO,Industrial CO Gas Transmitter:

Q: How do I install the Industrial CO Gas Transmitter?

A: Installation is straightforward: wall-mount the unit using the provided compact industrial mount. Ensure placement in the desired monitoring area, connect the DC 24V power supply, and integrate the signal output of your choice (4-20mA, RS485, or relay) with your control or monitoring system.

Q: What is the recommended calibration process, and how often should it be performed?

A: Calibration can be performed manually or automatically, depending on your application requirements. For optimal accuracy, regular calibration every 6-12 months is advised. Follow the provided instructions during setup, using certified calibration gases for precise adjustment.

Q: Where is this CO gas transmitter best suited for use?

A: This transmitter is ideal for industrial and hazardous environments with potential carbon monoxide exposure, such as factories, warehouses, workshops, or processing plants. Its IP65 protection ensures it can withstand dust and water, making it suitable for harsh ambient conditions.

Q: What benefits does the visual and audible alarm provide?

A: The built-in visual and audible alarms offer immediate notification in the event of dangerous CO gas levels, enabling rapid response and enhancing overall workplace safety. These alarms reduce the risk of prolonged exposure by alerting personnel swiftly.

Q: What is the expected service life of the sensor, and when should it be replaced?

A: The electrochemical CO sensor typically has a service life of 2-3 years under normal operating conditions. Replacement is recommended after this period or sooner if calibration fails to restore correct measurements.

Q: How accurate is the transmitter in detecting carbon monoxide levels?

A: The device provides high accuracy, measuring within 3% of the full scale (F.S.), allowing reliable detection and monitoring within a 0-1000 ppm test range.

Q: What environments and conditions can the transmitter operate in?

A: Designed for use in various industrial climates, it functions effectively in temperatures from -20C to +50C and humidity levels from 15% to 95% RH (non-condensing). The unit maintains performance in standard atmospheric pressure from 90-110 kPa.
