Handheld Gas Detector
Handheld Gas Detector
Handheld Gas Detector
Handheld Gas Detector
Handheld Gas Detector
Handheld Gas Detector

Handheld Gas Detector

Price 48000.0 INR/ Piece

MOQ : 1 Piece

Handheld Gas Detector Specification

  • Mounting Type
  • Handheld
  • Measuring Range
  • CH4: 0-100% LEL, O2: 0-30% VOL, CO: 0-1000 PPM, H2S: 0-100 PPM
  • Automation Grade
  • Manual
  • Equipment Type
  • Handheld Gas Detector
  • Test Range
  • Methane (CH4), Oxygen (O2), Carbon Monoxide (CO), Hydrogen Sulfide (H2S)
  • Operating Voltage
  • 3.7V
  • Interface Type
  • USB
  • Humidity
  • 0-95% RH (non-condensing)
  • Gas Pressure
  • Atmospheric
  • Resolution
  • CH4: 0.01% LEL, O2: 0.1% VOL, CO: 1 PPM, H2S: 0.1 PPM
  • Response Time
  • 30s
  • Power Supply
  • Rechargeable Li-ion Battery, USB charge
  • Display Type
  • LCD
  • Temperature
  • -20C to 50C
  • Max Height
  • 150mm
  • Accuracy
  • 5% Full Scale
  • Features
  • Multi-gas detection, Alarm system, Compact design
  • Application
  • Safety monitoring, Gas detection in industrial environments
  • Usage
  • Portable gas analysis
  • Machine Weight
  • 180g
  • Control Mode
  • Manual
  • Dimensions
  • 150mm x 80mm x 35mm
  • Operating Altitude
  • Up to 3000 meters
  • Storage Temperature
  • -40C to 60C
  • Alarm Type
  • Audible, Visual, and Vibration
  • Battery Life
  • 8-12 hours continuous use
  • Data Logging
  • Yes, internal memory
  • Alarm Thresholds
  • Configurable by user
  • Detection Principle
  • Electrochemical and Catalytic sensors
  • IP Rating
  • IP66 (Dust and water resistant)
  • Case Material
  • ABS Plastic with rubber coating
  • Calibration
  • Manual and Automatic



About Handheld Gas Detector

The Handheld Multi Gas Detector is a compact, portable, and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration monitoring with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its handheld design makes it suitable for personal safety, gas leak detection, confined-space entry, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector is suitable for use in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial applications, helping users identify hazardous gas conditions and maintain safer working environments.

Advanced Multi-Gas Detection

Equipped with cutting-edge electrochemical and catalytic sensors, this portable gas detector accurately monitors multiple gases including CH4, O2, CO, and H2S. It ensures workplace safety across diverse industrial applications and accommodates various atmospheric conditions. The customizable alarm system alerts users promptly to hazardous gas concentrations, supporting proactive hazard management.


Rugged, User-Friendly Design

Engineered with a tough ABS plastic and rubberized casing, the detector offers superior grip and resistance to dust and water (IP66 rated). Compact dimensions and light weight make it convenient for handheld use, while its LCD display aids quick status checks. Manual and automatic calibration options ensure precise measurements, instilling user confidence during critical safety monitoring tasks.


Efficient Data Management & Operation

The device's internal memory enables thorough data logging for traceability and compliance. Powered by a long-lasting rechargeable Li-ion battery (8-12 hours), it is suited for continuous operation in demanding environments. USB charging and easy interface further enhance daily usability, making routine maintenance and reporting streamlined for busy safety professionals.

FAQ's of Handheld Gas Detector:


Q: How does the Handheld Gas Detector alert users to hazardous gas levels?

A: The detector uses three alarm types-audible, visual, and vibration-to ensure users are immediately aware of dangerous gas concentrations. Alarm thresholds can be tailored by the user for each gas, allowing customized safety protocols.

Q: What is the typical battery life, and how is the device charged?

A: This gas detector provides 8-12 hours of continuous operation using a rechargeable Li-ion battery. Charging is straightforward via the built-in USB interface, making it compatible with standard USB power sources.

Q: When should the device be calibrated, and what are the calibration options?

A: Calibration is essential for accurate readings and should be performed regularly according to usage and workplace safety standards. The detector supports both manual and automatic calibration procedures, ensuring reliability in different field conditions.

Q: Where is this gas detector suitable for use?

A: With its IP66-rated case, the device is dust and water resistant, making it suitable for a wide range of industrial settings, including construction sites, chemical plants, and confined spaces where gas leaks are a safety concern.

Q: What types of gases can be detected and what are their test ranges?

A: The detector monitors methane (CH4) at 0-100% LEL, oxygen (O2) at 0-30% VOL, carbon monoxide (CO) at 0-1000 PPM, and hydrogen sulfide (H2S) at 0-100 PPM, covering essential safety monitoring needs in industrial environments.

Q: How is data managed and retrieved from the device?

A: All measurements are stored in its internal memory, facilitating data logging for compliance and analysis. Data can be easily downloaded to a computer via the USB interface for further review or reporting purposes.

Q: What are the key benefits of using this handheld detector in an industrial environment?

A: The main benefits include rapid and accurate multi-gas detection, customizable alerts for enhanced safety, long battery life for uninterrupted operation, and a rugged, portable design for ease of use in demanding environments.
