Handheld Gas Detector With Pump
Handheld Gas Detector With Pump
Handheld Gas Detector With Pump
Handheld Gas Detector With Pump
Handheld Gas Detector With Pump
Handheld Gas Detector With Pump

Handheld Gas Detector With Pump

Price 75000.0 INR/ Piece

MOQ : 1 Piece

Handheld Gas Detector With Pump Specification

  • Measuring Range
  • O2: 0-30%V/V, CO: 0-1000ppm, H2S: 0-100ppm, LEL: 0-100% LEL
  • Humidity
  • 0 to 95% RH (non-condensing)
  • Application
  • Industrial Safety, Confined Space, Environmental Monitoring
  • Resolution
  • O2: 0.1%, CO: 1ppm, H2S: 1ppm, LEL: 1%
  • Interface Type
  • Physical Buttons, LCD
  • Port Size
  • Standard Probe Connection
  • Test Range
  • O2: 0-30%V/V, CO: 0-1000ppm, H2S: 0-100ppm, LEL: 0-100% LEL
  • Gas Pressure
  • Atmospheric
  • Display Type
  • Digital LCD Display
  • Accuracy
  • 3% F.S. (varies by gas)
  • Features
  • Handheld, Built-in Pump, Multi-gas Detection, Rechargeable, Portable
  • Mounting Type
  • Handheld
  • Equipment Type
  • Handheld Gas Detector with Pump
  • Automation Grade
  • Manual
  • Power Supply
  • Rechargeable Li-ion Battery / 220V AC Adapter
  • Specimen Size
  • Handheld/Portable
  • Number of Specimens
  • Single Channel (Simultaneous Multi-gas Monitoring)
  • Operating Voltage
  • DC 3.7V (via rechargeable battery)
  • Response Time
  • <30 seconds
  • Temperature
  • -10C to +50C
  • Usage
  • Detection of Oxygen, Carbon Monoxide, Hydrogen Sulphide, LEL
  • Capacity
  • Multiple Gas Types
  • Machine Weight
  • Approx. 400g (including probe and battery)
  • Test Speed
  • Real-time/Continuous
  • Control Mode
  • Keypad Operation
  • Housing Material
  • High-impact ABS Plastic
  • Storage Capacity
  • Internal Memory for Data Logging
  • Calibration Mode
  • Manual/Automatic Calibration
  • Alarm
  • Visual, Audible, and Vibrating Alarms
  • Sampling Method
  • Built-in Suction Pump
  • Display Backlight
  • Yes
  • Battery Backup
  • Approximately 8 hours continuous use
  • Sensor Type
  • Electrochemical (O2, CO, H2S), Catalytic Bead (LEL)
  • Data Output
  • Optional USB for Data Transfer
  • Protection Grade
  • IP65 (Dust and Water Resistant)
  • Dimensions
  • Approx. 180mm x 80mm x 40mm



About Handheld Gas Detector With Pump

The Multi Gas Detector with Pump is a portable and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Equipped with an integrated sampling pump, it allows gas samples to be drawn from confined, enclosed, difficult-to-access, or remote areas for safer and convenient monitoring. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration measurement with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its portable design makes it suitable for gas leak detection, confined-space monitoring, personal safety, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector with pump is suitable for applications in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial environments, helping identify hazardous gas conditions and support safer operations.

Precise Detection with Multiple Sensors

Equipped with advanced electrochemical and catalytic bead sensors, this gas detector can accurately monitor oxygen, carbon monoxide, hydrogen sulphide, and combustible gases (LEL) in real-time. The device's detection range is engineered for versatile industrial and environmental monitoring, ensuring workers' safety in challenging conditions.


User-Friendly and Portable Design

Engineered for ease of use, this handheld gas detector weighs approximately 400 grams and features a compact design. The built-in suction pump offers efficient sampling, and a digital LCD with backlight provides high-visibility readings even in low-light environments. Physical button controls allow straightforward operation, making it suitable for a wide range of users.


Reliable Safety Features for Critical Environments

Designed with industrial safety in mind, this detector is housed in high-impact ABS plastic and carries an IP65 protection rating, safeguarding against dust and water. Visual, audible, and vibrating alarms provide immediate notifications of hazardous conditions, enabling timely responses during confined space entries or environmental assessments.

FAQ's of Handheld Gas Detector With Pump:


Q: How does the handheld gas detector operate and sample gases?

A: The device uses a built-in suction pump to actively draw air samples through the sensors, allowing real-time, continuous measurement of target gases. Its keypad and display interface enable simple user control and monitoring during operation.

Q: What types of gases can this detector measure simultaneously?

A: This handheld detector is designed to simultaneously monitor oxygen (O2), carbon monoxide (CO), hydrogen sulphide (H2S), and lower explosive limits of combustible gases (LEL), providing comprehensive safety coverage for various applications.

Q: When should I calibrate the gas detector and what methods are available?

A: Calibration should be performed before first use, after sensor replacement, or at intervals specified by your safety protocols. The detector supports both manual and automatic calibration options to maintain accurate measurements over time.

Q: Where can this gas detector be used effectively?

A: Ideal for industrial safety, confined space entry, and environmental monitoring, this detector is well-suited for use in factories, tanks, tunnels, and other locations where hazardous gases may be present.

Q: What is the data logging process and how can I transfer stored data?

A: The detector features internal memory for data logging, storing readings for review and compliance. Data can be exported via an optional USB interface, simplifying analysis, reporting, and record-keeping.

Q: How long does the battery last and what are the charging options?

A: The rechargeable Li-ion battery supports up to 8 hours of continuous use. The detector can be charged using the included 220V AC adapter, ensuring reliable operation during extended work shifts.

Q: What are the key benefits of using this handheld gas detector?

A: This device offers robust real-time monitoring, fast sampling, comprehensive multi-gas detection, and strong alarms in a portable, easy-to-use form. Its high-impact housing and IP65 protection enhance durability and safety in demanding work environments.
