Handheld Multi Gas Detector With Pump
Handheld Multi Gas Detector With Pump
Handheld Multi Gas Detector With Pump
Handheld Multi Gas Detector With Pump
Handheld Multi Gas Detector With Pump
Handheld Multi Gas Detector With Pump

Handheld Multi Gas Detector With Pump

Price 82000.0 INR/ Piece

MOQ : 1 Piece

Handheld Multi Gas Detector With Pump Specification

  • Port Size
  • Standard Quick Connect for Probe
  • Temperature
  • -10C to 50C
  • Features
  • Portable, Built-in Pump, Audible & Visual Alarms, Large LCD Display
  • Interface Type
  • Micro USB Charging/Power Interface
  • Humidity
  • 0-95% RH (Non-condensing)
  • Equipment Type
  • Handheld Multi Gas Detector With Pump
  • Specimen Size
  • Gas Sample via Probe
  • Power Supply
  • Rechargeable Lithium-ion Battery / External Power Adapter
  • Number of Specimens
  • Up to 4 Gases at Once
  • Operating Voltage
  • DC 3.7V (Battery Powered)
  • Gas Pressure
  • Atmospheric Pressure
  • Automation Grade
  • Semi-automatic
  • Response Time
  • 30 Seconds
  • Accuracy
  • 2% F.S.
  • Mounting Type
  • Handheld
  • Application
  • Industrial Safety, Confined Space Entry, Gas Leakage Detection
  • Test Range
  • O2: 0-30% V/V; CO: 0-1000 PPM; H2S: 0-100 PPM; LEL: 0-100% LEL
  • Display Type
  • Digital LCD Screen
  • Measuring Range
  • O2, CO, H2S, LEL (Customizable)
  • Resolution
  • O2: 0.1%, CO: 1 PPM, H2S: 0.1 PPM, LEL: 1%
  • Usage
  • Personal & Industrial Safety Monitoring
  • Capacity
  • Simultaneous detection of up to 4 gases
  • Machine Weight
  • Approximately 400 g (including battery and probe)
  • Test Speed
  • Real-time (continuous monitoring)
  • Control Mode
  • Manual Button Operation
  • Alarm Method
  • Audible Buzzer, Visual Indicator, On-screen Alerts
  • Sensor Type
  • Electrochemical and Catalytic Sensors
  • Calibration
  • User Calibration via Menu
  • Body Material
  • ABS Engineering Plastic Housing
  • Dimensions
  • Approx. 180mm x 80mm x 35mm
  • Sampling Method
  • Active Pump Suction Sampling
  • Operating Life
  • Up to 10 hours continuous (full charge)
  • Data Logging
  • Internal Storage for Event Records (Optional)
  • Sample Probe Length
  • Approx. 15 cm Stainless Steel Probe



About Handheld Multi Gas Detector With Pump

The Multi Gas Detector with Pump is a portable and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Equipped with an integrated sampling pump, it allows gas samples to be drawn from confined, enclosed, difficult-to-access, or remote areas for safer and convenient monitoring. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration measurement with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its portable design makes it suitable for gas leak detection, confined-space monitoring, personal safety, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector with pump is suitable for applications in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial environments, helping identify hazardous gas conditions and support safer operations.

Multi Gas Detection for Enhanced Safety

This detector simultaneously measures up to four hazardous gases, including O2, CO, H2S, and LEL. Its rapid, continuous monitoring and robust alarms make it indispensable for environments requiring vigilant gas surveillance, such as industrial sites and confined spaces. Automated and manual functions ensure reliable results and personal safety.


User-Friendly Operation and Calibration

The detector features manual button controls and user calibration via an intuitive menu. The digital LCD screen displays readings and alerts clearly, while internal storage enables event data logging. Active sampling with a stainless steel probe streamlines detection-even in challenging locations.


Durability and Portability

Encased in ABS engineering plastic, the device is lightweight yet strong for handheld use. With a rechargeable lithium-ion battery and micro USB charging interface, the detector supports extended field operations. Its compact design, robust probe, and quick-connect ports enable easy, everyday use for professionals.

FAQ's of Handheld Multi Gas Detector With Pump:


Q: How does the Handheld Multi Gas Detector With Pump sample gases for detection?

A: The device uses active pump suction sampling, drawing gas through a 15 cm stainless steel probe for real-time analysis of up to four different gases simultaneously.

Q: What types of sensors are integrated in this gas detector?

A: The detector incorporates both electrochemical and catalytic sensors for accurate measurement of O2, CO, H2S, and LEL gases within industrial environments.

Q: When should the device be calibrated, and what is the process for calibration?

A: Calibration should be performed as recommended by your safety protocol, especially before critical operations. The process is user-friendly, accessed through the menu for automated calibration routines using reference gases.

Q: Where can the Handheld Multi Gas Detector be used effectively?

A: This equipment is suitable for a variety of places, including confined spaces, factories, warehouses, construction sites, and anywhere industrial safety monitoring is critical.

Q: What methods does the detector employ to alert users of dangerous gas levels?

A: It features an audible buzzer, visual indicator lights, and on-screen alerts on its digital LCD, ensuring hazards are noticed promptly in high-risk environments.

Q: How long can the device operate continuously on a full charge, and how is it powered?

A: The detector operates up to 10 hours on a full charge via its rechargeable lithium-ion battery, and can also be powered externally through a micro USB interface.

Q: What are the benefits of using this multi gas detector for industrial safety monitoring?

A: Benefits include simultaneous detection of multiple gases, portable handheld design, strong alarms, event data logging, clear digital readouts, and sturdy construction-all contributing to improved workplace safety and efficiency.
