Industrial Multi Gas Detector with Pump
Industrial Multi Gas Detector with Pump
Industrial Multi Gas Detector with Pump
Industrial Multi Gas Detector with Pump
Industrial Multi Gas Detector with Pump
Industrial Multi Gas Detector with Pump

Industrial Multi Gas Detector with Pump

Price 78000.0 INR/ Piece

MOQ : 1 Piece

Industrial Multi Gas Detector with Pump Specification

  • Application
  • Industrial safety, confined space monitoring, gas leak detection
  • Accuracy
  • 2% full scale
  • Temperature
  • -10C to +50C
  • Resolution
  • O2: 0.1%; CO: 1 PPM; H2S: 1 PPM; LEL: 1% LEL
  • Measuring Range
  • O2: 0-30% V/V; CO: 0-1000 PPM; H2S: 0-100 PPM; LEL: 0-100% LEL
  • Port Size
  • Standard probe fitting
  • Automation Grade
  • Semi-automatic
  • Response Time
  • <20 seconds
  • Operating Voltage
  • DC 3.7V or AC 230V
  • Test Range
  • O2: 0-30% V/V; CO: 0-1000 PPM; H2S: 0-100 PPM; LEL: 0-100% LEL
  • Number of Specimens
  • Single point measurement
  • Interface Type
  • Probe connector with digital interface
  • Features
  • Built-in pump, programmable alarm, real-time display, portable, robust
  • Gas Pressure
  • Atmospheric
  • Power Supply
  • Rechargeable Li-ion Battery or 230V AC Adapter
  • Mounting Type
  • Handheld/Portable
  • Equipment Type
  • Industrial Multi Gas Detector with Pump
  • Display Type
  • Digital LCD display
  • Humidity
  • 0-95% RH (non-condensing)
  • Usage
  • Portable field detection
  • Capacity
  • Simultaneous multi-gas detection
  • Machine Weight
  • Approx. 600g (including probe)
  • Test Speed
  • Instantaneous measurement
  • Control Mode
  • Manual/Automatic
  • Probe Length
  • 150 mm
  • Battery Life
  • 8 hours continuous operation
  • Data Logging
  • Built-in memory for historical data
  • Dimensions
  • 210mm x 85mm x 40mm
  • Gas Sampling Method
  • Active pump suction
  • Sensor Type
  • Electrochemical and catalytic
  • Calibration
  • Auto-calibration feature
  • Alarm Type
  • Audio/Visual/Vibration
  • Protection Rating
  • IP54



About Industrial Multi Gas Detector with Pump

The Multi Gas Detector with Pump is a portable and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Equipped with an integrated sampling pump, it allows gas samples to be drawn from confined, enclosed, difficult-to-access, or remote areas for safer and convenient monitoring. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration measurement with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its portable design makes it suitable for gas leak detection, confined-space monitoring, personal safety, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector with pump is suitable for applications in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial environments, helping identify hazardous gas conditions and support safer operations.

Advanced Multi-Gas Detection Technology

Equipped with both electrochemical and catalytic sensors, this detector simultaneously measures O2, CO, H2S, and LEL concentrations. Its active pump suction sampling ensures rapid and reliable readings, suitable for varied industrial applications including safety assessments and leak detection. The digital LCD display provides real-time results, making it essential for on-site monitoring.


Reliable Alarm and Data Management

The device offers programmable alarms with audio, visual, and vibration notifications to alert users instantly of unsafe gas levels. Built-in memory allows for historical data logging, supporting thorough safety audits and compliance records. Efficient and user-friendly, it helps maintain safe working conditions.


Durable, Portable, and Easy to Use

With a robust IP54 rating and ergonomic handheld design, this multi-gas detector is fit for harsh operational environments. Its 8-hour battery life, automatic calibration, and instantaneous measurement capabilities make it ideal for field work. The detector's straightforward probe connector and digital interface simplify both sampling and maintenance.

FAQ's of Industrial Multi Gas Detector with Pump:


Q: How does the Industrial Multi Gas Detector with Pump sample and detect gases?

A: This detector uses an active pump suction method via a 150 mm probe, drawing gaseous samples into its electrochemical and catalytic sensors. It instantly measures O2, CO, H2S, and LEL levels and displays real-time data on the digital LCD screen.

Q: What advantages does the built-in memory and data logging feature provide?

A: The built-in memory stores historical measurement data, allowing users to review past readings for safety audits, incident investigations, and regulatory compliance. It ensures thorough record-keeping without the need for separate logging devices.

Q: When should I perform calibration on the detector, and how is it done?

A: Calibration is essential before initial use, after sensor replacement, or periodically as recommended by the manufacturer. The auto-calibration feature simplifies the process, ensuring measurement accuracy and reliability.

Q: Where can this multi-gas detector be used safely?

A: It is suitable for use in industrial settings, confined spaces, field inspections, and environments requiring gas leak detection and safety monitoring. Its IP54 rating allows it to operate in areas with dust and water splashes.

Q: What is the process for measuring gases using this equipment?

A: Insert the probe into the target area, select manual or automatic control mode, and initiate measurement. Readings appear almost instantly, with alarms triggered if unsafe gas concentrations are detected. Data is logged automatically for future reference.

Q: How does the device alert users to hazardous gas levels?

A: Upon detecting harmful gas concentrations, the device activates programmable alarms, which include audio, visual, and vibration signals to warn users immediately, enabling rapid response to potential hazards.

Q: What benefits does the handheld design and rechargeable battery offer for field work?

A: The ergonomic, portable design and 8-hour Li-ion battery enable easy transportation and extended use in the field. Quick charging and the option of AC power ensure uninterrupted operation during critical safety checks.
