Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device

Portable Multi Gas Monitoring Device

Price 84000.0 INR/ Piece

MOQ : 1 Piece

Portable Multi Gas Monitoring Device Specification

  • Operating Voltage
  • DC 3.7V (Li-ion battery)
  • Measuring Range
  • Multiple gases (O2, CO, H2S, LEL)
  • Display Type
  • LCD digital display
  • Max Height
  • 160mm
  • Automation Grade
  • Automatic
  • Port Size
  • Standard inlet for probe
  • Features
  • Portable, Easy-to-read display, Multi-Gas Detection
  • Application
  • Industrial Safety, Laboratory, Environmental Monitoring
  • Test Range
  • O2 (0-25% V/V), CO (0-1000PPM), H2S (0-100PPM), LEL (0-100% LEL)
  • Interface Type
  • USB/Data output
  • Resolution
  • O2 (0.1%), CO (1ppm), H2S (1ppm), LEL (1%)
  • Gas Pressure
  • Atmospheric
  • Accuracy
  • 2% F.S.
  • Mounting Type
  • Handheld
  • Equipment Type
  • Portable Multi Gas Monitoring Device
  • Temperature
  • -10C to 50C
  • Power Supply
  • Battery powered (Rechargeable) / USB
  • Humidity
  • 0-95% RH (Non-condensing)
  • Response Time
  • 20 seconds
  • Usage
  • Gas concentration measurement
  • Capacity
  • Multi Gas Detection
  • Machine Weight
  • Approx. 300g
  • Test Speed
  • Instant
  • Control Mode
  • Manual & Auto
  • Alarm Type
  • Audible (Buzzer) & Visual Alarm
  • Languages Available
  • English
  • Calibration
  • User calibratable
  • Probe Type
  • Removable gas probe
  • Sensor Type
  • Electrochemical & Catalytic
  • Sampling Mode
  • Diffusion & Probe
  • Storage Temperature
  • -20C to 60C
  • Data Logging
  • Yes, internal memory capability
  • Enclosure Material
  • ABS Plastic
  • Operating Principle
  • Continuous real-time monitoring
  • Battery Life
  • Up to 12 hours continuous operation
  • Protection Level
  • IP54 (Dust and Splash resistant)



About Portable Multi Gas Monitoring Device

The Multi Gas Detector with Pump is a portable and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Equipped with an integrated sampling pump, it allows gas samples to be drawn from confined, enclosed, difficult-to-access, or remote areas for safer and convenient monitoring. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration measurement with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its portable design makes it suitable for gas leak detection, confined-space monitoring, personal safety, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector with pump is suitable for applications in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial environments, helping identify hazardous gas conditions and support safer operations.

Advanced Multi-Gas Detection

With built-in electrochemical and catalytic sensors, this device accurately monitors oxygen, carbon monoxide, hydrogen sulfide, and flammable gases. Designed for industrial and environmental use, it delivers real-time data and instant response, ensuring safety in diverse settings. The high-resolution LCD display provides clear readings, facilitating rapid analysis and decision-making.


Robust Data Logging & Calibration

Internal memory enables comprehensive data logging, allowing users to track measurements over time. User-calibratable sensors make maintenance straightforward, while USB interface supports seamless data output. The device adapts to manual or automatic control modes, enhancing operational flexibility and reliability.


Portable & Durable Design

Constructed from ABS plastic and rated IP54, the device is dust- and splash-resistant, suitable for challenging environments. Weighing approximately 300g and handheld, it is convenient for fieldwork. The rechargeable battery delivers up to 12 hours of continuous operation, ensuring extended usability during long shifts.

FAQ's of Portable Multi Gas Monitoring Device:


Q: How does the Portable Multi Gas Monitoring Device measure gas concentration?

A: The device utilizes electrochemical and catalytic sensors for continuous, real-time measurement of gas concentrations. Users can select diffusion or probe sampling modes to detect O2, CO, H2S, and LEL levels instantly.

Q: What types of alarms does this device provide for gas detection?

A: It offers both audible (buzzer) and visual alarms to notify users promptly when detected concentrations exceed safety thresholds, safeguarding personnel in hazardous conditions.

Q: When should the device be calibrated and how is calibration performed?

A: Calibration is recommended at regular intervals or before critical use to ensure accuracy. Users can calibrate the sensors using integrated functions, following the onscreen instructions displayed on the LCD digital display.

Q: Where can the Portable Multi Gas Monitoring Device be used?

A: This device is ideal for industrial safety, laboratory analysis, and environmental monitoring. Its robust design and IP54 protection allow it to operate reliably in dusty and splash-prone environments.

Q: What is the benefit of data logging and internal memory in this equipment?

A: Internal memory supports extensive data logging, enabling users to review measurement histories, analyze trends, and maintain compliance with safety regulations. Data can be exported via USB interface for further analysis.

Q: How long does the battery last, and what charging options are available?

A: The rechargeable Li-ion battery provides up to 12 hours of continuous operation. The device can be recharged using a USB power supply, offering convenience for field and laboratory use.

Q: What are the main advantages of using this device for gas detection?

A: Key benefits include instant response, high accuracy, multi-gas detection capability, user calibration, easy-to-read digital display, data logging, and durable dust/splash-resistant construction, making it highly suitable for varied and demanding environments.
