Professional Single Gas Detector With Pump
Professional Single Gas Detector With Pump
Professional Single Gas Detector With Pump
Professional Single Gas Detector With Pump
Professional Single Gas Detector With Pump
Professional Single Gas Detector With Pump
Professional Single Gas Detector With Pump
Professional Single Gas Detector With Pump

Professional Single Gas Detector With Pump

Price 41000.0 INR/ Unit

MOQ : 1 Unit

Professional Single Gas Detector With Pump Specification

  • Specimen Size
  • Portable Device
  • Gas Pressure
  • Atmospheric
  • Frequency
  • Continuous Measurement
  • Response Time
  • 5 seconds
  • Application
  • Industrial, Environmental Monitoring, laboratory, confined space entry
  • Power Supply
  • Rechargeable Li-ion battery / USB Power Adapter
  • Display Type
  • LCD Digital Display
  • Humidity
  • 0-95% RH (non-condensing)
  • Features
  • Portable, Pump assisted sampling, Alarm function, Easy operation
  • Number of Specimens
  • Single Gas Detection
  • Resolution
  • 0.1% Vol
  • Measuring Range
  • O2: 0-100% Vol
  • Interface Type
  • Push Button, USB Charging
  • Automation Grade
  • Manual
  • Max Height
  • 180 mm approx.
  • Hardness
  • Plastic body
  • Equipment Type
  • Professional Single Gas Detector with Pump
  • Port Size
  • Standard sampling port for tubing
  • Accuracy
  • 0.5% Vol
  • Temperature
  • -20C to 50C
  • Test Range
  • 0-100% Vol (Oxygen)
  • Operating Voltage
  • DC 3.7V
  • Mounting Type
  • Handheld
  • Usage
  • Gas concentration measurement
  • Capacity
  • Single Gas Monitoring
  • Machine Weight
  • Approx. 350g (including batteries)
  • Test Speed
  • Real-time measurement
  • Control Mode
  • Manual/Push-button
  • Start-up Time
  • <30 seconds
  • Sensor Type
  • Electrochemical Sensor
  • Protection Grade
  • IP54
  • Dimension
  • 180 x 70 x 35 mm
  • Battery Life
  • Up to 24 hours operation
  • Operating Language
  • English
  • Data Logging
  • Optional
  • Indicator
  • LED status indicator
  • Alarm Type
  • Audible and Visual Alarm
  • Maintenance
  • Self-diagnostic & sensor fault indication
  • Model Number
  • ATS-101M
  • Sampling Method
  • Pump assisted
  • Calibration
  • Manual/Automatic



About Professional Single Gas Detector With Pump

The Handheld Single Gas Detector With Pump is a compact and portable gas detection instrument designed for reliable monitoring of a specific gas in industrial, hazardous and confined-space environments. The integrated sampling pump enables active gas sampling from locations that are difficult to access, providing convenient and reliable detection of oxygen, toxic, combustible and other hazardous gases. Available in different gas configurations, the detector is suitable for personal safety, gas leak detection, confined-space entry, process monitoring and routine workplace gas monitoring. Its rugged handheld design makes it suitable for applications across oil & gas, oil refineries, petrochemical, chemical, pharmaceutical, fertilizer, power plants, steel, mining, battery manufacturing and other industrial sectors. The detector provides clear gas concentration readings along with visual and audible alarms when preset gas levels are reached, making it suitable for a wide range of industrial gas detection and safety applications.

Reliable Gas Detection with Real-Time Results

ATS-101M delivers prompt, accurate gas concentration readings through real-time measurement and a sensitive electrochemical sensor. The device notifies users instantly of hazardous levels via both audible and visual alarms. Its rapid response time and portable form factor make it ideal for immediate safety assurance in a variety of operational environments where single gas monitoring is essential.


Enhanced Usability and Maintenance

Equipped with a push-button interface and LCD digital display, the detector is straightforward to operate even in demanding situations. Self-diagnostic and sensor fault indication add to its dependability, reducing downtime due to maintenance. The unit also offers manual or automatic calibration to maintain accuracy over time, while easy USB charging supports convenient field operation.

FAQ's of Professional Single Gas Detector With Pump:


Q: How do I operate the Professional Single Gas Detector with Pump (ATS-101M)?

A: To operate the ATS-101M, power on the device using the push-button interface. The detector begins measuring gas concentrations in real time within 30 seconds of startup. Sampling is pump-assisted for reliable detection, and all measurements can be viewed on the LCD digital display. Audible and visual alarms alert you when gas levels exceed preset thresholds.

Q: What gases can the ATS-101M measure, and in which environments is it suitable?

A: This model is configured for single gas monitoring, such as oxygen, within a measuring range of 0-100% Vol. It is suitable for use in industrial environments, laboratories, environmental monitoring, and confined space entry, where portable, accurate, and rapid gas detection is critical.

Q: When should I calibrate the gas detector, and how is calibration done?

A: Calibration should be performed prior to use in new environments or periodically as part of your safety protocol. The ATS-101M supports both manual and automatic calibration methods, ensuring accurate measurements. Follow the calibration instructions provided in the user manual for optimal results.

Q: Where can I use the ATS-101M for effective gas detection?

A: Thanks to its compact, handheld design and IP54 protection grade, the ATS-101M can be safely used in a variety of locations, including industrial plants, confined spaces, laboratories, and field monitoring scenarios where single gas detection is needed.

Q: What maintenance does the gas detector require?

A: The ATS-101M features self-diagnostic functions, including sensor fault indication, to assist with timely maintenance. Regularly check the LED status indicator and follow prompts for any required sensor or battery maintenance. Consult the manual for detailed maintenance instructions.

Q: How does the device alert users to hazardous gas levels?

A: Whenever gas concentrations reach or exceed the preset limits, the detector immediately activates both audible and visual alarms, ensuring users are promptly informed of potential danger. The LED status provides additional indication of device status.

Q: What are the benefits of using this portable single gas detector?

A: Benefits include real-time, accurate detection, fast response (5 seconds), a lightweight and portable design for convenience, reliable alarms, user-friendly operation, and flexible calibration and charging options. These features contribute to enhanced workplace safety and efficiency in gas monitoring tasks.
