Handheld Explosive Gas Detector Model ATS 101M

Price 32500 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Handheld Explosive Gas Detector Model ATS 101M Specification

Temperature
-10C to +55C

Application
Detection of explosive gases in confined spaces

Resolution
0.1% LEL

Measuring Range
0-100% LEL

Automation Grade
Manual

Equipment Type
Handheld Explosive Gas Detector

Power Supply
3.7V rechargeable Li-ion battery

Mounting Type
Handheld

Response Time
30s

Max Height
15cm

Accuracy
5%FS

Display Type
Digital LCD

Humidity
0-95% RH (non-condensing)

Operating Voltage
DC 3.7V

Features
Audible and visual alarm, real-time gas concentration display

Interface Type
Mini USB (charging)

Usage
Industrial safety, leakage detection

Machine Weight
250g

Control Mode
Manual

Battery Life
Up to 10 hours continuous operation

Alarm Set Point
Adjustable, typically 10-20% LEL

Protection Class
IP54

Dimensions
170 mm x 45 mm x 27 mm

Storage Temperature
-20°C to +60°C

Calibration
User calibration with standard gas

Sensor Type
Catalytic combustion

Alarm Type
LED indicator light and 85 dB buzzer

About Handheld Explosive Gas Detector Model ATS 101M

This light, Handheld Model ATS 101M combustible gas leak detector is the perfect tool locating leaks of combustible gases such as Compressed Natural Gas (CNG), Liqufied Petroleum Gas (LPG)Liqufied Natural Gas (LNG), Methane (CH4), Hydrogen (H2), Carbon Dioxide (CO2).

ESCRIPTION APPLICATIONS

Liquefied Petroleum as (LPG)
Compressed Natural Gas (CNG)
Methane (CH4)
Natural Gas (NG)
Hydrogen (H2)
Carbon Dioxide (CO2)

Reliable Gas Detection for Safety-Critical Environments

Designed for industrial and confined space applications, the ATS 101M delivers accurate real-time results to help protect lives and property. With its catalytic combustion sensor, the device quickly detects a range of explosive gases and triggers audible and visual alarms if concentrations surpass safe levels. Its impressive battery life and ergonomic handheld design make it suitable for extended field use, supporting worker safety in diverse conditions.

User-Friendly Features and Flexible Calibration

The ATS 101M stands out with a digital LCD display for immediate readings, adjustable alarm set points, and simple user calibration using standard gases. Maintenance and operation are straightforward thanks to manual control, Mini USB charging, and a durable Li-ion battery, ensuring ease of use for exporters, manufacturers, and safety professionals alike. The compact dimensions and lightweight build enhance portability without compromising on capability.

FAQs of Handheld Explosive Gas Detector Model ATS 101M:

Q: How is the sensor in the ATS 101M gas detector calibrated?

A: Calibration is performed by the user with a standard gas. The device provides a manual calibration mode, allowing you to ensure accurate and reliable readings consistently.

Q: What types of alarms does the ATS 101M provide for gas detection?

A: The ATS 101M is equipped with both an LED indicator light and an 85 dB buzzer that activate when gas concentrations reach the adjustable alarm set point, typically set between 10-20% LEL for early warning.

Q: When should I use the ATS 101M handheld gas detector?

A: This detector is ideal for use whenever there is a risk of explosive gas accumulation, such as during industrial inspections, leakage detection, or maintenance in confined spaces.

Q: Where can the ATS 101M be operated effectively?

A: The device operates reliably in industrial or hazardous locations where explosive gases may be present, and functions across temperatures from -10C to +55C and in humid environments up to 95% RH non-condensing.

Q: What is the benefit of the real-time gas concentration display?

A: The digital LCD shows instant gas concentration readings, enabling prompt decision-making to enhance workplace safety and facilitate quick responses in case of dangerous gas buildup.

Q: How long does the battery last and how is it charged?

A: The ATS 101M provides up to 10 hours of continuous operation on a single charge. The rechargeable 3.7V Li-ion battery can be conveniently charged using the Mini USB interface.
