Multi Gas Detection Instrument
Multi Gas Detection Instrument
Multi Gas Detection Instrument
Multi Gas Detection Instrument
Multi Gas Detection Instrument
Multi Gas Detection Instrument

Multi Gas Detection Instrument

Price 47000.0 INR/ Piece

MOQ : 1 Piece

Multi Gas Detection Instrument Specification

  • Test Range
  • CH4: 0-100% LEL; O2: 0-25% VOL; CO: 0-1000 PPM; H2S: 0-100 PPM
  • Response Time
  • <30 seconds
  • Gas Pressure
  • Atmospheric
  • Automation Grade
  • Manual
  • Humidity
  • 0% - 95% RH (Non-condensing)
  • Operating Voltage
  • 3.7V DC (Battery)
  • Application
  • Industrial Safety, Environmental Monitoring, Confined Spaces
  • Mounting Type
  • Handheld/Portable
  • Temperature
  • -20C to +50C
  • Power Supply
  • Rechargeable Lithium Battery
  • Features
  • Simultaneous detection, Audible & Visual Alarms, Data logging
  • Interface Type
  • Physical buttons, USB Charging
  • Measuring Range
  • CH4: 0-100% LEL; O2: 0-25% VOL; CO: 0-1000 PPM; H2S: 0-100 PPM
  • Accuracy
  • 2% of Full Scale
  • Resolution
  • CH4: 0.01% LEL; O2: 0.1% VOL; CO: 1 PPM; H2S: 1 PPM
  • Port Size
  • Standard Sampling Port
  • Display Type
  • Digital LCD
  • Usage
  • Personal gas safety monitoring
  • Machine Weight
  • Approx. 250g
  • Test Speed
  • Instantaneous (Real-time)
  • Control Mode
  • Button Operated
  • Data Logging
  • Up to 100,000 records
  • Equipment Type
  • Multi Gas Detection Instrument
  • Alarm Mode
  • Audible, Visual & Vibrating
  • Detection Type
  • Electrochemical and catalytic sensors
  • Operating Time
  • 8-12 hours (Full Charge)
  • Enclosure Material
  • ABS Plastic
  • Waterproof Level
  • IP65
  • Storage Temperature
  • -20C to +60C
  • Dimensions
  • Approx. 140mm x 70mm x 40mm
  • Calibration Interval
  • Annually or as required
  • Charging Port
  • Micro USB
  • Sensor Life
  • 2-3 Years (Typical)



About Multi Gas Detection Instrument

The Handheld Multi Gas Detector is a compact, portable, and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration monitoring with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its handheld design makes it suitable for personal safety, gas leak detection, confined-space entry, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector is suitable for use in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial applications, helping users identify hazardous gas conditions and maintain safer working environments.

Reliable Safety Monitoring for Industrial Use

Engineered for personal and workplace safety, this Multi Gas Detection Instrument delivers dependable gas monitoring in various challenging conditions. Its waterproof IP65 rating makes it suitable for harsh environments, while the sturdy ABS plastic housing ensures durability. The instrument enables simultaneous detection of methane, oxygen, carbon monoxide, and hydrogen sulfide, covering a broad measuring range for each gas. Audible, visual, and vibrating alarms provide immediate alerts, making it ideal for use in industrial safety, confined spaces, and environmental assessments.


User-Friendly Operation and Comprehensive Data Logging

Designed for ease of use, the detector is equipped with physical buttons and an intuitive digital LCD for clear readings. Simple to operate, it can be easily carried or mounted, making it perfect for fieldwork and personal safety monitoring. The device offers extensive data logging capabilities-up to 100,000 records-enabling comprehensive review and analysis of gas exposure events. Annual calibration or as required ensures accuracy, and the battery is conveniently recharged via a Micro USB port.

FAQ's of Multi Gas Detection Instrument:


Q: How does the Multi Gas Detection Instrument alert users of hazardous gas levels?

A: The instrument notifies users through three built-in alarm modes: audible, visual, and vibrating. When the device detects gas concentrations above preset thresholds, it activates these alerts instantaneously, ensuring prompt awareness and facilitating swift action to maintain safety.

Q: What types of gases can this detector measure and with what accuracy?

A: This detector identifies methane (CH4), oxygen (O2), carbon monoxide (CO), and hydrogen sulfide (H2S) using electrochemical and catalytic sensors. The device achieves an accuracy of 2% of full scale, providing reliable and precise readings for each gas within their specific measuring ranges.

Q: When does the detector require calibration, and what is the calibration process?

A: Calibration is recommended annually or as needed depending on usage and environmental conditions. The process involves exposing the instrument to standard calibration gases and following the manufacturer's instructions to adjust readings, ensuring ongoing accuracy and performance.

Q: Where can the Multi Gas Detection Instrument be employed effectively?

A: This device is designed for use in industrial safety, environmental monitoring, and confined space applications. It is suitable for monitoring gas concentrations in manufacturing plants, refineries, tunnels, mines, and any environment where gas hazards need to be managed.

Q: What is the typical operating time on a full battery charge, and how is it recharged?

A: On a full charge, the detector operates for 8 to 12 hours, sufficient for most work shifts. It is powered by a rechargeable lithium battery, and recharging is done easily via the built-in Micro USB port.

Q: How much data can the instrument log, and what is the benefit of this feature?

A: The detector can store up to 100,000 records, providing a comprehensive log of all measurements and alarm events. This extensive data logging supports safety audits, compliance reporting, and in-depth incident analysis.

Q: What are the benefits of using this Multi Gas Detection Instrument for safety monitoring?

A: The instrument offers real-time, simultaneous detection of multiple hazardous gases with rapid response and high accuracy. Its portability, rugged design, and multiple alarm systems significantly enhance personal and workplace safety, supporting effective risk management and incident prevention.
