Online SO2 Gas Analyser

Price 275500 INR/ Set

Get a Price/Quote

MOQ : 1 Set

Online SO2 Gas Analyser Specification

Power Supply
230 V AC 50 Hz

Usage
Industrial

Humidity
< 85%RH

Accuracy
+2 %

Temperature
15 Celsius (oC)

Machine Weight
1.5 Kilograms (kg)

Control Mode
with control key

Online SO2 Gas Analyser Trade Information

Minimum Order Quantity
1 Set

FOB Port
Mumbai

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
25 Sets Per Week

Delivery Time
1-2 Week

Sample Policy
Within a certain price range free samples are available

Packaging Details
Normal Packing

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
TUV

About Online SO2 Gas Analyser

With our sophisticated production unit, we are able to provide pristine quality Online SO2 Gas Analyzer. This analyzer is manufactured by utilizing high grade components and pioneering technology as per the instructions provided by our seasoned professionals in tandem with market quality norms. Provided analyzer is used for combustion efficiency testing in several industries. Our clients can purchase this Onlioine SO2 Gas Analyzer from us us in numerous specifications at marginal prices within the stipulated time frame.

Features :-

Impeccable performance
Easy to operate
Compact design
Longer service life

Descriptions:

Model ATS- 208A Emission Analyzer continuously monitors the concentration of gases ranging from 100%V/V down to PPM level. Feature includes a duel wavelength sensor, Remote Sampling, Graphics LCD Display, adjustable level relay output for alarm and 4-20mA output for control purpose and minimal maintenance.
Special gas sample Conditioning systems are used to clean and dry the gas sample for accurate and High performance operation. An Internal Pump draw gas sample into the sensor through a dust particle filter from an intake which can be located at distance up to 40 meter form the monitor.
The Sensor and Electronic component are housed in tough aluminium housing

Specifications:-

Principle: Electrochemical, TCD (Thermal Conductivity) , NDIR (Non Dispersive Infrared ), Zirconium and Paramagnetic
Range: %V/V, % LEL, PPM, Mg/M3
Resolution: 0.1 Unit or 1 Unit (Application based)
Sampling Method: Auto Suction
Display: 320 X 264 Graphic LCD
Alarm; Relay Contact NO+NC
Anolog Out Put: 4-20mA
Digital Out Put : RS 232, RS 485 and Modbus Communication Protocol
Power Source: 230VAC
Accuracy: +/2%
Response Time: <5 Second
Sensor Life: 2-3 Years
Environmental:
Temperature:-15degree Celsius Humidity :< 85%RH Atmosphere Pressure: 86- 106Kpa
Dimension in mm: 430 (W) X 150(H) X 250(D)
Weight: 2.5 KG
Warranty: One Year

Accurate SO2 Monitoring for Industrial Environments

Our Online SO2 Gas Analyser enables continuous sulfur dioxide measurement, offering real-time monitoring crucial for process industries and environmental compliance. With advanced accuracy and a practical operating range, this analyser is suitable for demanding industrial sites, safeguarding workplace safety and meeting emission standards.

Effortless Control and Installation

Featuring a user-friendly control key and compact design, the SO2 analyser is easy to set up and operate. The lightweight structure (1.5 kg) and compatibility with standard 230 V AC 50 Hz power supplies guarantee flexibility and hassle-free deployment across diverse industrial facilities in India.

FAQs of Online SO2 Gas Analyser:

Q: How does the Online SO2 Gas Analyser function in industrial settings?

A: The Online SO2 Gas Analyser continuously monitors sulfur dioxide levels in real time, providing reliable data for environmental safety and process control. Its accurate sensor and user-friendly control key allow operators to easily manage the monitoring process within specified temperature and humidity ranges.

Q: What is the typical installation process for this SO2 analyser?

A: Installation is straightforward due to its compact size and lightweight design. Simply connect the analyser to a 230 V AC 50 Hz power supply and ensure environmental conditions are maintained at 15C with humidity below 85% RH for optimal performance.

Q: When should this analyser be used in industrial applications?

A: The analyser is ideal for use during industrial processes where SO2 emissions must be monitored, such as in chemical plants, power stations, and environmental monitoring stations. It helps ensure ongoing compliance with safety and emission standards.

Q: Where can the Online SO2 Gas Analyser be purchased or serviced in India?

A: We supply, export, import, manufacture, and service the Online SO2 Gas Analyser throughout India, offering support at every stage from purchasing to maintenance.

Q: What advantages does this analyser offer over conventional monitoring methods?

A: This analyser provides real-time, highly accurate SO2 detection (2% accuracy), fast response, and convenient operation through its control key, improving safety and efficiency compared to manual or delayed sampling methods.

Q: How should the analyser be maintained for continued reliability?

A: Regular cleaning, periodic calibration, and keeping the analyser within recommended temperature and humidity limits will uphold its accuracy and longevity, ensuring ongoing reliability in industrial operations.
