Portable Nitrogen Purity Analyser

Price 75000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Piece

Portable Nitrogen Purity Analyser Specification

Application
Industrial

Measuring Range
0-99.99% N2 Celsius (oC)

Features
Portable, Battery Operated, Backlit Display, Data Logging

Power Supply
Rechargeable Lithium Battery, 7.4V DC

Usage
Gas analysis

Test Range
0-99.99% (Nitrogen)

Mounting Type
Handheld

Classification
IP65

Number of Specimens
Single Sample

Product Type
Gas analyzer

Operating Voltage
7.4V DC Volt (V)

Equipment Type
Portable Gas Analyser

Specimen Size
25 Centimeter (cm)

Port Size
1/8 inch NPT

Humidity
0-99% RH

Resolution
0.01%

Temperature
0 C to 50 C Celsius (oC)

Gas Pressure
0-1.0 MPa mpa

Display Type
Digital LCD

Response Time
10 seconds Seconds

Interface Type
RS232/USB

Automation Grade
Automatic

Accuracy
0.3% %

Machine Weight
1.5 kg Kilograms (kg)

Test Speed
Instantaneous

Control Mode
Microprocessor Based

Data Storage
Up to 1000 readings

Material of Construction
ABS Body

Enclosure Protection
IP54

Gas Type Supported
Nitrogen (N2)

Alarm Output
Audible and Visual

Warm-up Time
<30 seconds

Operating Time (Battery)
8-10 hours continuous

Sensor Type
Electrochemical/Oxygen Sensor

Calibration Method
Manual and Automatic

Dimensions (LxWxH)
220 x 80 x 45 mm

Portable Nitrogen Purity Analyser Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

About Portable Nitrogen Purity Analyser

Features	Complete Automatic Operation
Drift	+- 1% of full scale max. Per day
Minimum Resolution	0.01 %
Detection Principle	Thermal Conductivity / Infrared.
Sampling	In built sample pump and flow regulator
Sampling Method	In Built Suction Pump
Range	0% - 99.99 % V/V.
Readout	128 x 64 Graphics LCD
Country of Origin	Made in India
Usage/Application	Industrial Use

Instantaneous and Reliable Analysis

Rely on the analyser's rapid test speed-results appear in 10 seconds or less, ensuring efficiency in industrial environments where immediate nitrogen purity information is critical. With its high accuracy and resolution, you can confidently conduct quality assessments for a wide range of applications.

User-Friendly and Portable Design

Engineered for mobility, the ABS-body analyser weighs just 1.5 kg and fits comfortably in hand. The backlit digital LCD, ergonomic controls, and intuitive interface make it perfect for on-site operations, even in demanding conditions with high humidity or varied temperatures.

Robust Data Handling and Safety

The analyser not only logs up to 1000 readings for traceability but also maximizes user safety through both visual and audible alarms. It is built to withstand harsh settings (IP54 rated) and operates reliably across a broad temperature and humidity range, ideal for diverse Indian industrial sectors.

FAQ's of Portable Nitrogen Purity Analyser:

Q: How does the Portable Nitrogen Purity Analyser function?

A: This analyser measures nitrogen purity by using an electrochemical/oxygen sensor. Gas enters through a standard 1/8 inch NPT port, and the device instantly determines N2 levels (0-99.99%) using microprocessor-based controls, displaying results on the digital LCD.

Q: What are the supported applications and typical usage of this analyser?

A: The analyser is designed for on-site measurement of nitrogen purity in industrial gases. It is widely used by exporters, importers, manufacturers, service providers, and suppliers to verify product quality and ensure process compliance.

Q: When should the calibration process be performed?

A: Calibration can be performed manually or automatically. It is typically recommended before starting a new analysis session, after extended storage, or whenever accuracy verification is required by quality protocols.

Q: Where can this analyser be used effectively?

A: Thanks to its portable, handheld design and IP54 enclosure, the analyser is suitable for a variety of industrial and field settings across India, including factories, laboratories, gas production plants, and on-site service locations.

Q: What safety features does the analyser provide during operation?

A: The device offers both visual and audible alarms to promptly warn users of purity deviations or abnormal sensor readings, thus helping prevent operational errors and ensuring safe gas analysis.

Q: How is data stored and retrieved from the analyser?

A: Up to 1000 readings are stored internally. Data can be accessed via RS232 or USB interface, enabling efficient logging, traceability, and further analysis as per documentation needs.

Q: What benefits does the analyser offer for industrial gas analysis?

A: Its rapid, accurate readings, easy portability, robust construction, and substantial data storage streamline both routine and critical gas purity assessment tasks-enhancing efficiency and reliability for industrial operations.
