Turbine Gas Analyser

The Hydrogen Purity and Purge Gas analyzer have been design especially for cylindrical and power station to check the Hydrogen Purity. The Analyzer is supplied in robust and reliable construction having Li-IONE rechargeable battery with 6 Hour of continuous operation. The integral Pump, Needle valve and Flow meter are used to control the sample through the analyzer during the monitoring of alternator gases.

Specifications:

• Principle:  Thermal Conductivity and NDIR (Non dispersive Infrared )
• Range: %V/V
• Resolution: 0.1 Unit or 1 Unit (Application based)
• Sampling Method:  Auto Suction or Direct Plug In
• Display:  128 X 64 Graphics LCD
• Alarm; Two Levels Low & High, Visual and Audible
• Power Source: Built in Lithium Rechargeable battery
• Accuracy: +/2%
• Response Time: <5 Second
• Data Storage: 5000 or 10000
• Computer Interface: RS 232, USB, RS485
• Sensor Life: 4-5 Years
• Operating Time: 6 to 8 hours

Environmental:

• Temperature:-15degree Celsius Humidity :< 85%RH Atmosphere Pressure: 86-   106Kpa
• Housing: High Impact Plastic
• Dimension in mm: 200 (W) X 120 (H) X 185(D)
• Weight: 1.5 KG
• Warranty: One Year
