Gas Detector With Integrated Pump
Gas Detector With Integrated Pump
Gas Detector With Integrated Pump
Gas Detector With Integrated Pump
Gas Detector With Integrated Pump
Gas Detector With Integrated Pump
Gas Detector With Integrated Pump
Gas Detector With Integrated Pump

Gas Detector With Integrated Pump

Price 45000.0 INR/ Piece

MOQ : 1 Piece

Gas Detector With Integrated Pump Specification

  • Measuring Range
  • 0-100% Volume Oxygen
  • Operating Voltage
  • 3.7V DC
  • Resolution
  • 0.1% Vol
  • Port Size
  • Standard Gas Sampling Inlet
  • Features
  • Integrated Sample Pump, Alarm Function, Lightweight, Portable
  • Response Time
  • < 10 seconds
  • Humidity
  • 0-95% RH (non condensing)
  • Power Supply
  • Rechargeable Lithium Battery
  • Accuracy
  • 2% of reading
  • Application
  • Industrial Gas Monitoring, Confined Space Monitoring, Safety & Environment
  • Mounting Type
  • Handheld
  • Display Type
  • Digital LCD Display
  • Interface Type
  • USB charging port
  • Test Range
  • 0 to 100% Vol Oxygen (O2)
  • Automation Grade
  • Manual
  • Gas Pressure
  • Atmospheric pressure range
  • Temperature
  • -10C to 50C
  • Usage
  • Gas Monitoring for Oxygen (O2)
  • Machine Weight
  • Approx. 350 g
  • Control Mode
  • Manual push buttons
  • Battery Backup
  • Up to 12 hours continuous operation
  • Data Logging
  • Optional
  • Casing Material
  • ABS Plastic
  • Sampling Method
  • Active aspirated
  • Charging Time
  • 2-3 hours
  • Model Number
  • ATS-101M
  • Operating Environment
  • Indoor & Outdoor
  • Alarm Type
  • Audio and Visual
  • Sensor Type
  • Electrochemical
  • Dimensions
  • 188 x 92 x 45 mm
  • Equipment Type
  • Handheld Gas Detector with Integrated Pump
  • Pump Type
  • Integrated diaphragm pump
  • Calibration Method
  • User adjustable



About Gas Detector With Integrated Pump

The Handheld Single Gas Detector With Pump is a compact and portable gas detection instrument designed for reliable monitoring of a specific gas in industrial, hazardous and confined-space environments. The integrated sampling pump enables active gas sampling from locations that are difficult to access, providing convenient and reliable detection of oxygen, toxic, combustible and other hazardous gases. Available in different gas configurations, the detector is suitable for personal safety, gas leak detection, confined-space entry, process monitoring and routine workplace gas monitoring. Its rugged handheld design makes it suitable for applications across oil & gas, oil refineries, petrochemical, chemical, pharmaceutical, fertilizer, power plants, steel, mining, battery manufacturing and other industrial sectors. The detector provides clear gas concentration readings along with visual and audible alarms when preset gas levels are reached, making it suitable for a wide range of industrial gas detection and safety applications.

Continuous and Reliable Gas Monitoring

The ATS-101M provides consistent and accurate oxygen concentration readings in both indoor and outdoor environments. Thanks to its integrated pump and active aspirated sampling, users can rely on fast, efficient data collection even in challenging environments. Its precision and robustness make it particularly suitable for industrial and confined space operations where safety and timely response are crucial.


User-Friendly Interface and Operation

Equipped with a digital LCD display and intuitive push-button controls, the ATS-101M simplifies monitoring procedures. Users can easily adjust calibration settings, monitor battery status, and interpret real-time data. The handheld, lightweight design enhances portability while the rechargeable lithium battery guarantees up to 12 hours of uninterrupted monitoring per charge, supporting extended shifts and prolonged fieldwork.


Safety Features and Versatility

This device is engineered with both audio and visual alarm systems to ensure alerts are immediately noticed. Its robust ABS casing, wide operating temperature range, and non-condensing humidity tolerance guarantee dependable function in a variety of industrial and safety environments. Optional data logging allows historical tracking for compliance and analysis purposes, broadening its application in safety management and environmental monitoring.

FAQ's of Gas Detector With Integrated Pump:


Q: How does the ATS-101M handheld gas detector operate in confined or hazardous spaces?

A: The ATS-101M is engineered for both indoor and outdoor use, including confined or hazardous environments. Its integrated diaphragm pump actively draws air samples through the standard gas sampling inlet, ensuring accurate and timely oxygen level detection. The device's rapid response time of less than 10 seconds provides immediate readings, making it ideal for safety assessments in potentially risky areas.

Q: What benefits does the integrated diaphragm pump provide compared to other sampling methods?

A: The active aspirated sampling with the integrated diaphragm pump ensures more precise and quicker acquisition of gas samples compared to passive diffusion methods. This is especially beneficial for monitoring in spaces where rapid assessment of oxygen levels is critical for worker safety and compliance.

Q: When should the ATS-101M be calibrated and how is the calibration process performed?

A: Regular calibration is recommended before each use or as dictated by workplace safety protocols. The ATS-101M features user-adjustable calibration, allowing operators to easily set calibration using manual push buttons, ensuring ongoing accuracy in measurement results.

Q: What is the battery backup and charging routine for the ATS-101M?

A: The device provides up to 12 hours of continuous operation on a full charge. It uses a rechargeable lithium battery and can be charged via a standard USB charging port. Charging typically takes 2-3 hours, making it suitable for daily industrial operations or extended fieldwork.

Q: Where is the ATS-101M best utilized?

A: This model is most effective in industrial gas monitoring, confined space safety checks, and environmental safety assessments. Its rugged design, portability, and accurate monitoring make it a versatile choice for factories, maintenance sites, laboratories, and any location where oxygen monitoring is essential.

Q: What types of alarms are integrated and how do they enhance user safety?

A: The ATS-101M incorporates both loud audio and clear visual alarms, which promptly alert users when oxygen levels fall outside preset safe ranges. This dual alarm system helps ensure that critical warnings are not missed, contributing to improved safety in hazardous environments.

Q: What are the advantages of the ATS-101M for frequent field usage?

A: Weighing approximately 350 grams and designed for handheld use, the ATS-101M is lightweight and portable. Its robust ABS casing, manual controls, and prolonged battery life enable reliable gas detection during fieldwork, maintenance rounds, or safety audits, without the need for frequent recharging or recalibration.
