Handheld Gas Monitoring Instrument
Handheld Gas Monitoring Instrument
Handheld Gas Monitoring Instrument
Handheld Gas Monitoring Instrument
Handheld Gas Monitoring Instrument
Handheld Gas Monitoring Instrument

Handheld Gas Monitoring Instrument

Price 45000.0 INR/ Piece

MOQ : 1 Piece

Handheld Gas Monitoring Instrument Specification

  • Temperature
  • -20C to +50C
  • Test Range
  • CH4 (%LEL), O2 (%VOL), CO (PPM), H2S (PPM)
  • Specimen Size
  • Handheld Size
  • Accuracy
  • 2% F.S.
  • Power Supply
  • Rechargeable Lithium Battery
  • Number of Specimens
  • 1 (Single Use)
  • Interface Type
  • Physical Buttons, Standard Port
  • Equipment Type
  • Handheld Gas Monitoring Instrument
  • Application
  • Industrial Safety, Environmental Monitoring
  • Features
  • Real-time Monitoring, Audible/Visual Alarm, Rechargeable
  • Humidity
  • 0~95% RH (non-condensing)
  • Port Size
  • Standard Gas Intake Port
  • Gas Pressure
  • Atmospheric
  • Automation Grade
  • Semi-automatic
  • Mounting Type
  • Handheld
  • Display Type
  • LCD Digital Display
  • Measuring Range
  • CH4: 0-100% LEL, O2: 0-30% VOL, CO: 0-1000 PPM, H2S: 0-100 PPM
  • Frequency
  • Continuous operation
  • Response Time
  • <30s
  • Operating Voltage
  • 3.7V DC
  • Resolution
  • CH4: 0.01% LEL, O2: 0.1% VOL, CO: 1 PPM, H2S: 1 PPM
  • Max Height
  • 17cm
  • Usage
  • Gas Leak Detection
  • Capacity
  • Multi-gas detection
  • Machine Weight
  • Approx. 250g
  • Test Speed
  • Instantaneous
  • Control Mode
  • Manual
  • Case Material
  • ABS Plastic and Rubber
  • Dimensions
  • 170mm x 75mm x 40mm
  • Charging Time
  • Approximately 4 hours
  • Alarm Mode
  • Audible, Visual, Vibrating
  • IP Rating
  • IP65 (Dust and Water Resistant)
  • Operating Environment
  • Suitable for confined spaces, hazardous areas
  • Alarm Setting
  • Adjustable threshold
  • Data Logging
  • Available
  • Calibration Interval
  • 6 months
  • Battery Life
  • Up to 12 hours continuous use
  • Storage Temperature
  • -30C to +60C
  • Sensor Type
  • Electrochemical & Catalytic Sensor



About Handheld Gas Monitoring Instrument

The Handheld Multi Gas Detector is a compact, portable, and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration monitoring with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its handheld design makes it suitable for personal safety, gas leak detection, confined-space entry, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector is suitable for use in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial applications, helping users identify hazardous gas conditions and maintain safer working environments.

Advanced Multi-Gas Detection

Utilizing both electrochemical and catalytic sensors, this handheld device offers precise and instantaneous monitoring of methane, oxygen, carbon monoxide, and hydrogen sulfide. It supports a wide measuring range and delivers results within 30 seconds, making it ideal for swift safety assessments in various industrial settings.


User-Centric Alarming System

Designed with adjustable threshold alarms, this instrument provides real-time awareness through customizable audible, visual, and vibrating alerts. Safety is further enhanced by immediate notification of hazardous conditions, making it suitable for high-risk, confined space work environments.


Durable and Ergonomic Design

Built from robust ABS plastic and rubber, and rated IP65 for dust and water resistance, this gas detector withstands harsh industrial environments. Its compact size and light weight ensure comfortable and safe handheld usage during extended inspections.

FAQ's of Handheld Gas Monitoring Instrument:


Q: How does the instrument notify users of hazardous gas levels?

A: The device incorporates multiple alarm modes-audible, visual, and vibrating-that can be set to trigger at adjustable thresholds, immediately alerting users to dangerous gas concentrations for timely action.

Q: What is the recommended calibration process and interval for this gas detector?

A: For accurate and reliable measurements, the instrument should be calibrated every six months. Calibration involves exposing the sensors to known concentrations of target gases based on the manufacturer's procedure.

Q: Where can this gas monitoring instrument be safely used?

A: With its IP65 rating and durable ABS and rubber casing, the instrument is suitable for confined spaces and hazardous areas such as industrial sites, manufacturing plants, and outdoor environments requiring environmental monitoring.

Q: What are the main benefits of using this handheld gas detector?

A: Key benefits include real-time monitoring of multiple gases with high resolution, immediate alarms for hazardous exposures, robust portability, long (up to 12 hour) battery life, and a simple user interface, enhancing safety and compliance in critical environments.

Q: How is charging managed and how long does it take to fully recharge the battery?

A: The instrument operates on a rechargeable lithium battery and requires approximately 4 hours to fully recharge, providing up to 12 hours of continuous operation when fully charged.

Q: What are the available data logging features and how does it benefit users?

A: Onboard data logging stores measurement readings, enabling incident review and compliance reporting. This feature proves valuable for ongoing safety audits and environmental records.

Q: What is the process of using the instrument for gas leak detection?

A: To begin, power the device on, confirm calibration status, and select the desired monitoring range. Move the handheld device through the suspected area-real-time readings and instant alarms will alert you if gas levels exceed safe thresholds.
