Multi Gas Detector Instrument
Multi Gas Detector Instrument
Multi Gas Detector Instrument
Multi Gas Detector Instrument
Multi Gas Detector Instrument
Multi Gas Detector Instrument

Multi Gas Detector Instrument

Price 50000.0 INR/ Piece

MOQ : 1 Piece

Multi Gas Detector Instrument Specification

  • Temperature
  • -20C to 50C
  • Max Height
  • 150mm
  • Operating Voltage
  • 3.7V
  • Application
  • Industrial safety, mining, confined space monitoring
  • Power Supply
  • Rechargeable Lithium-ion Battery
  • Automation Grade
  • Semi-Automatic
  • Accuracy
  • 2% full scale
  • Humidity
  • 0-95% RH non-condensing
  • Resolution
  • CH4: 0.01% LEL, O2: 0.1% VOL, CO: 1 PPM, H2S: 0.1 PPM
  • Gas Pressure
  • Atmospheric
  • Features
  • Real-time data monitoring, audible & visual alarm, calibration function
  • Port Size
  • Standard gas inlet port
  • Test Range
  • CH4, O2, CO, H2S
  • Interface Type
  • Keypad, USB (for charging)
  • Response Time
  • 20 Seconds
  • Mounting Type
  • Handheld/Portable
  • Measuring Range
  • CH4: 0-100% LEL, O2: 0-30% VOL, CO: 0-1000 PPM, H2S: 0-100 PPM
  • Display Type
  • LCD Digital Display
  • Usage
  • Detection of combustible and toxic gases
  • Machine Weight
  • 250g
  • Control Mode
  • Manual/Automatic
  • Ingress Protection
  • IP65
  • Alarm Levels
  • User adjustable (high/low thresholds)
  • Equipment Type
  • Portable Multi Gas Detector
  • Operating Altitude
  • Up to 2000m
  • Data Logging
  • Up to 1000 records
  • Firmware Update
  • Via USB
  • Battery Life
  • >8 hours continuous operation
  • Sensor Type
  • Electrochemical (O2, CO, H2S), Catalytic (CH4)
  • Dimensions
  • 150mm x 75mm x 40mm
  • Calibration Interval
  • 6 months recommended
  • Alarm Type
  • Buzzer, Flashing light, Vibration



About Multi Gas Detector Instrument

The Handheld Multi Gas Detector is a compact, portable, and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration monitoring with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its handheld design makes it suitable for personal safety, gas leak detection, confined-space entry, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector is suitable for use in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial applications, helping users identify hazardous gas conditions and maintain safer working environments.

Advanced Gas Detection Technology

Utilizing electrochemical sensors for oxygen, carbon monoxide, and hydrogen sulfide, along with a catalytic sensor for methane, this detector offers robust multi-gas monitoring. The instrument ensures precise readings, with quick response times-delivering results within just 20 seconds, vital for safety-critical industries.


Rugged and User-Friendly Design

Designed for portability, the detector weighs only 250g and features a compact form factor, allowing ease of use in various industrial environments. Its IP65 rating protects against dust and water ingress, while a large LCD digital display and intuitive keypad interface enhance usability during field operations.


Smart Alarm and Data Capabilities

With dual alarm levels, configurable by the user, and three alert modes-buzzer, flashing light, and vibration-the detector immediately signals hazardous conditions. Data logging functionality stores up to 1,000 records, facilitating trend analysis and compliance documentation for safety audits.

FAQ's of Multi Gas Detector Instrument:


Q: How do I calibrate the multi gas detector and how often should it be done?

A: The detector should be calibrated every six months to maintain accuracy. Calibration can be performed using standard calibration gases and following the device's manual calibration function. This process ensures the sensors remain accurate for reliable gas detection.

Q: What gases can this multi gas detector measure and within what ranges?

A: This portable detector measures methane (CH4: 0-100% LEL), oxygen (O2: 0-30% VOL), carbon monoxide (CO: 0-1000 PPM), and hydrogen sulfide (H2S: 0-100 PPM), providing essential coverage for industrial safety applications.

Q: Where can the portable multi gas detector be used effectively?

A: It is ideal for industrial safety monitoring, mining operations, and confined spaces where hazardous gases may be present. Its rugged, portable design and high ingress protection allow for use in challenging environments up to 2000 meters altitude.

Q: What is the process for updating the firmware on this instrument?

A: Firmware updates are performed via the USB interface. Simply connect the detector to a PC and follow the manufacturer's firmware update procedure, ensuring your device benefits from the latest enhancements and fixes.

Q: How does the alarm system ensure prompt warning in dangerous situations?

A: The detector features audible alarms (buzzer), visual indicators (flashing lights), and a vibration alert. With user-adjustable high and low thresholds, it promptly notifies users of gas concentrations exceeding safe limits, maximising safety.

Q: What are the benefits of the device's data logging capability?

A: The data logger can record up to 1,000 entries, allowing users to track gas exposure over time. This feature is invaluable for safety compliance, workplace audits, and identifying potential gas hazard trends.

Q: How long will the detector operate on a full charge and what type of battery does it use?

A: The device is powered by a rechargeable lithium-ion battery, delivering more than 8 hours of continuous operation, ensuring dependable monitoring throughout a standard work shift.
