Portable Single Gas Monitor
Portable Single Gas Monitor
Portable Single Gas Monitor
Portable Single Gas Monitor
Portable Single Gas Monitor
Portable Single Gas Monitor
Portable Single Gas Monitor
Portable Single Gas Monitor

Portable Single Gas Monitor

Price 41000.0 INR/ Piece

MOQ : 1 Piece

Portable Single Gas Monitor Specification

  • Accuracy
  • 0.2% Vol. O2
  • Operating Voltage
  • 3.7V DC (Rechargeable Battery)
  • Automation Grade
  • Manual
  • Specimen Size
  • Handheld
  • Mounting Type
  • Handheld / Portable
  • Port Size
  • Standard Gas Inlet Port
  • Features
  • Lightweight, Handheld, Rechargeable, Audio/Visual Alarm, Large Digital Display
  • Application
  • Industrial Safety, Laboratories, Medical, Environmental Monitoring
  • Interface Type
  • User Button Interface
  • Humidity
  • 0-95% RH (non-condensing)
  • Number of Specimens
  • Single Channel
  • Test Range
  • 0-30% Vol. O2 (Oxygen)
  • Gas Pressure
  • Atmospheric
  • Resolution
  • 0.1% Vol. O2
  • Measuring Range
  • 0-30% Vol. Oxygen (O2)
  • Hardness
  • ABS Engineering Plastic Housing
  • Equipment Type
  • Portable Single Gas Monitor
  • Display Type
  • Digital LCD Display
  • Response Time
  • 10 seconds
  • Power Supply
  • Rechargeable Li-ion Battery / USB charging
  • Max Height
  • Pocket Size, ~180mm
  • Temperature
  • -10C to +50C
  • Usage
  • Single Gas Monitoring
  • Capacity
  • Single Gas Detection
  • Machine Weight
  • Approx. 250g
  • Control Mode
  • Manual Control
  • Sensor Type
  • Electrochemical Oxygen Sensor
  • Calibration
  • User Calibratable
  • Alarm Notification
  • Audio & Visual Alarm on Threshold Breach
  • Model
  • ATS-101M
  • Battery Backup
  • Up to 24 hours continuous use
  • Data Logging
  • Optional
  • Ingress Protection
  • IP54



About Portable Single Gas Monitor

The Handheld Single Gas Detector With Pump is a compact and portable gas detection instrument designed for reliable monitoring of a specific gas in industrial, hazardous and confined-space environments. The integrated sampling pump enables active gas sampling from locations that are difficult to access, providing convenient and reliable detection of oxygen, toxic, combustible and other hazardous gases. Available in different gas configurations, the detector is suitable for personal safety, gas leak detection, confined-space entry, process monitoring and routine workplace gas monitoring. Its rugged handheld design makes it suitable for applications across oil & gas, oil refineries, petrochemical, chemical, pharmaceutical, fertilizer, power plants, steel, mining, battery manufacturing and other industrial sectors. The detector provides clear gas concentration readings along with visual and audible alarms when preset gas levels are reached, making it suitable for a wide range of industrial gas detection and safety applications.

Reliable Oxygen Detection for Safety Assurance

The ATS-101M offers accurate single-gas monitoring with superior reliability, making it a preferred tool for safety professionals. Its electrochemical sensor provides fast response and precise measurements within 0.2% Vol. O2 accuracy. The handheld device ensures users are promptly alerted to hazardous oxygen levels with both audio and visual alarms, enhancing safety and peace of mind in various industrial and laboratory environments.


User-Friendly, Portable, and Durable Design

Designed for convenience, the ATS-101M weighs approximately 250g and fits easily in hand or pocket. Its robust ABS engineering plastic housing ensures durability, and the manual user button interface enables easy operation and calibration. The digital LCD display delivers clear, real-time data, supporting quick decision-making even in challenging conditions. USB charging and up to 24 hours battery backup guarantee uninterrupted performance.

FAQ's of Portable Single Gas Monitor:


Q: How does the ATS-101M Portable Single Gas Monitor notify users of oxygen level breaches?

A: The ATS-101M is equipped with both audio and visual alarms that activate instantly when oxygen concentrations exceed or fall below preset thresholds, ensuring timely notification and quick response to unsafe conditions.

Q: What environments are suitable for using the ATS-101M?

A: This monitor is ideal for industrial safety, laboratories, medical facilities, and environmental monitoring where accurate oxygen level detection is crucial. Its IP54 rating offers protection in moderately dusty and humid settings.

Q: How do users calibrate the ATS-101M monitor?

A: Calibration is user-enabled via a simple manual process using the device's button interface and a certified gas standard. Regular calibration helps maintain measurement accuracy and device reliability.

Q: What is the typical process for charging the ATS-101M?

A: Charging is accomplished through the included USB cable, connecting the device to a compatible power source. A full battery provides up to 24 hours of continuous monitoring, making the device ready for daily fieldwork.

Q: What are the primary benefits of the ATS-101M's handheld design?

A: Its pocket-sized, lightweight construction ensures ease of mobility and extended use without fatigue, while the rugged ABS housing offers strong protection in diverse environments.

Q: When is data logging available on the ATS-101M, and how is it used?

A: Data logging is an optional feature that enables users to record oxygen level readings over time. This is particularly useful for compliance monitoring and trend analysis in professional settings.
