Multi Gas Monitoring Device
Multi Gas Monitoring Device
Multi Gas Monitoring Device
Multi Gas Monitoring Device
Multi Gas Monitoring Device
Multi Gas Monitoring Device

Multi Gas Monitoring Device

Price 83000.0 INR/ Unit

MOQ : 1 Unit

Multi Gas Monitoring Device Specification

  • Interface Type
  • Push button controls
  • Test Range
  • O2: 0-30% V/V, CO: 0-999 PPM, H2S: 0-100 PPM, LEL: 0-100% LEL
  • Measuring Range
  • O2: 0-30% V/V, CO: 0-999 PPM, H2S: 0-100 PPM, LEL: 0-100% LEL
  • Equipment Type
  • Handheld Multi-Gas Monitoring Device
  • Number of Specimens
  • Multi-channel (up to 4 gases simultaneously)
  • Port Size
  • 1 Probe Port
  • Application
  • Personal and workplace safety, confined space monitoring, Industrial Gas Detection
  • Humidity
  • 0-95% RH (non-condensing)
  • Resolution
  • O2: 0.1%, CO: 1 PPM, H2S: 1 PPM, LEL: 1%
  • Power Supply
  • Rechargeable battery 3.7V / USB Adapter
  • Gas Pressure
  • Ambient atmospheric conditions
  • Operating Voltage
  • 3.7V rechargeable battery
  • Response Time
  • <30 seconds
  • Mounting Type
  • Handheld / Portable
  • Features
  • Simultaneous multi-gas detection, Audio/Visual Alarm, Portable design, Data Logging (Optional)
  • Display Type
  • Large digital LCD display
  • Accuracy
  • 2% FS (typical, depends on sensor)
  • Temperature
  • -10C to 50C
  • Automation Grade
  • Automatic (Microprocessor-based)
  • Usage
  • Gas concentration detection in field and industry
  • Capacity
  • Continuous monitoring mode
  • Machine Weight
  • Approx. 400 g (with battery)
  • Control Mode
  • Microprocessor based digital control
  • Alarm Type
  • Visual & Audible Alarm on hazardous limits exceeded
  • Calibration
  • User programmable, 3-point calibration system
  • Environmental Protection
  • IP54 dust & splash proof
  • Sampling Method
  • Diffusion / Manual Suction Probe
  • Battery Life
  • Up to 8 hours (continuous operation)
  • Data Storage
  • Optional Data Logging feature
  • Casing Material
  • ABS Industrial-grade plastic
  • Dimensions
  • 210 mm x 85 mm x 40 mm (without probe)
  • Accessories Included
  • Sampling probe, charger, operation manual
  • Sensor Life
  • Approx. 2 years (sensor dependent)
  • Display Backlight
  • Available for low light operation
  • Compliance
  • Meets relevant IS/IEC/EN standards



About Multi Gas Monitoring Device

The Multi Gas Detector with Pump is a portable and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Equipped with an integrated sampling pump, it allows gas samples to be drawn from confined, enclosed, difficult-to-access, or remote areas for safer and convenient monitoring. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration measurement with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its portable design makes it suitable for gas leak detection, confined-space monitoring, personal safety, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector with pump is suitable for applications in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial environments, helping identify hazardous gas conditions and support safer operations.

Simultaneous Multi-Gas Detection

Detect up to four hazardous gases at once, including O2, CO, H2S, and LEL. Real-time monitoring and quick response ensure safety in both industrial and field environments, helping protect personnel during confined space entry or routine inspections.


User-Friendly Operation and Calibration

The device features push-button controls and a user-programmable 3-point calibration system. Operators can calibrate sensors as required for optimal accuracy. Each sensor typically lasts about two years, depending on usage conditions and gas exposure.


Durable, Portable Design

With ABS industrial-grade plastic casing and IP54 dust and splash protection, the monitor is ideal for rugged field or industrial applications. Its compact, lightweight build and rechargeable battery provide up to 8 hours of continuous operation, making it easy to carry through the workday.

FAQ's of Multi Gas Monitoring Device:


Q: How does the Multi-Gas Monitoring Device detect multiple gases simultaneously?

A: The device utilizes a multi-channel sensor system, allowing up to four different gases-O2, CO, H2S, and LEL-to be monitored at the same time in real-time. Sampling can be performed via diffusion or manual suction probe, ensuring accurate and timely detection.

Q: What is the process for calibrating the device, and how often should it be done?

A: Calibration is user-programmable using a 3-point calibration system. It is recommended to calibrate the device periodically, such as before critical measurements or after sensor replacement, to maintain optimal accuracy and compliance with standards.

Q: When should I expect to replace the gas sensors in the device?

A: Sensor life typically lasts around two years depending on the specific sensor and environmental exposure. Replacement is advised if accuracy declines or after prolonged usage under heavy gas concentrations.

Q: Where can the device be used, and what environmental conditions does it tolerate?

A: The monitor operates reliably in industrial, field, or confined space environments. It is protected against dust and splashes (IP54 rated) and functions across a wide range of temperatures (-10C to 50C) and humidity (0-95% RH, non-condensing).

Q: What are the main benefits of using this Multi-Gas Monitoring Device?

A: Key benefits include simultaneous detection of multiple gases, visual and audible alarms for hazardous levels, portable design, rugged casing, long battery life, optional data logging, and compliance with IS/IEC/EN standards. These features enhance workplace safety and operational efficiency.

Q: How is data stored and accessed from the device?

A: The device offers optional data logging functionality, enabling storage of measurement data for review and analysis. Data can be accessed and managed as needed, supporting documentation and regulatory compliance.

Q: What accessories are included with the Multi-Gas Monitoring Device?

A: Each unit comes with a sampling probe, charger, and operation manual, ensuring users have all necessary tools for immediate deployment and safe gas detection.
