Portable Gas Analyzer

Product Description

Portable Gas Analyzer Model ATS-206A

Compact, Portable construction and simplicity of operation makes Applied Portable Gas Analyser a valuable aid for insitute use in constantly changing measurement sites.

The highly upgradable ATS - 206A model can be AC Powered and/or Battery operated. It may include a chargeable battery charger, Sampling Probe with condensate trap and an inline Micro Filter and an inbuilt Sampling Pump. It can be built to include upto 8 Nos. of Gas Sensors and Temperature Sensor, Draft/ Pressure besides the calculated parameters and have option of

• Data Logger
• Integral Printer
• RS 232 Output
• Date & Time
• Facility for Automation

Specifications:

• Display : Graphics LCD
• Sampling : Through inbuilt Sampling Pump.
• Zero Calibration:Automatic at instrument startup with fresh air sample
• SPAN Calibration:Automatic span areas  (Fresh air for oxygen)
• Response time:30 sec at 95 % variation
• Power Supply :110V or 220V & AC Ni-cad battery pack with integral charger.
• Working Temperature : -5 to 55C
• Storage Temperature : -20 to 50C
• Probe Length : SS 600 mm length standard (900 & 1200 mm optional)
• Probe Diameter : 8mm (12mm optional)
• Battery life: 6 hours continuous operation
• Data Memory : 500 readings for each gases.
• Printer : Impact type 24 columns.
• Printing speed : 0.75 lines / seconds.
• Alarms : Visual and audible, 4 Alarms
• Digital Interface : RS 232/USB
• User Data : 2 lines of 16 characters
• Case : Rigid Aluminum
• External Dimensions : 280 x 210 x 185 mm
• Weight (Gross) : < 2 kg. with batteries (Approx.)
• Interference Filters : Provided with Sensors
• Line Filter : Replaceable 5 microns
• Accessories : Water Trap
• Preprogrammed Fuels : Light & Heavy Diesel Oil, Gas, Coal, Furnace Oil, Wood
• Special Fuels - preprogrammed on request.

Applications:

• Ambient and Emissions Monitoring
• Stack or Exhaust Gas Analysis in Boilers
• Power & Industrial Plants
• Process Analysis
• Fuel Efficiency
• Internal Combustion
