Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device
Portable Multi Gas Monitoring Device

Portable Multi Gas Monitoring Device

Price 45000.0 INR/ Piece

MOQ : 1 Piece

Portable Multi Gas Monitoring Device Specification

  • Automation Grade
  • Automatic
  • Features
  • Portable, Multi-gas detection, Alarm (audio/visual/vibration), Backlit display
  • Measuring Range
  • CH4: 0-100% LEL, O2: 0-30% VOL, CO: 0-1000 PPM, H2S: 0-100 PPM
  • Display Type
  • LCD Digital Display
  • Accuracy
  • 5% of reading
  • Humidity
  • 0-95% RH (non-condensing)
  • Interface Type
  • USB port for charging
  • Resolution
  • CH4: 1%LEL, O2: 0.1%, CO: 1 PPM, H2S: 1 PPM
  • Application
  • Industrial Safety, Confined Spaces, Gas Detection
  • Response Time
  • 30 seconds
  • Operating Voltage
  • 3.7V
  • Power Supply
  • Rechargeable Li-ion Battery 3.7V
  • Test Range
  • CH4: 0-100% LEL, O2: 0-30% VOL, CO: 0-1000 PPM, H2S: 0-100 PPM
  • Temperature
  • -20C ~ +50C
  • Mounting Type
  • Handheld
  • Gas Pressure
  • Atmospheric
  • Port Size
  • 3 mm inlet
  • Usage
  • Real-time detection of hazardous gases
  • Machine Weight
  • 230 g
  • Control Mode
  • Microprocessor Control
  • Alarm Type
  • Sound, Light, Vibration
  • Sampling Method
  • Diffusion
  • Material
  • ABS plastic, Rubberized case
  • Calibration
  • Manual/Auto
  • Ingress Protection
  • IP65
  • Equipment Type
  • Portable Multi Gas Monitoring Device
  • Data Logging
  • Optional USB export
  • Dimension
  • 60 130 40 mm
  • Operating Time
  • Up to 8 hours continuous
  • Charging Time
  • Approx. 4 hours
  • Color
  • Yellow/Black
  • Operating Environment
  • Indoor/Outdoor
  • Sensor Type
  • Electrochemical / Catalytic
  • Gas Detected
  • Methane (CH4), Oxygen (O2), Carbon Monoxide (CO), Hydrogen Sulfide (H2S)



About Portable Multi Gas Monitoring Device

The Handheld Multi Gas Detector is a compact, portable, and reliable gas monitoring instrument designed for the simultaneous detection and measurement of multiple hazardous gases in industrial and commercial environments. Depending on the sensor configuration, it can detect gases such as Oxygen (O), Hydrogen Sulfide (HS), Carbon Monoxide (CO), Sulfur Dioxide (SO), Hydrogen (H), combustible gases, VOCs, and other toxic or flammable gases. The detector provides fast and accurate gas concentration monitoring with a clear digital display and audible, visual, and vibration alarms for effective hazard notification. Its handheld design makes it suitable for personal safety, gas leak detection, confined-space entry, plant inspection, maintenance, process monitoring, emergency response, and workplace safety. The multi gas detector is suitable for use in Oil Refineries, Petrochemical, Chemical, Oil & Gas, Natural Gas, LNG/LPG, Fertilizer, Coal Mining, Power Plants, Iron & Steel, Foundries, Pharmaceutical, Battery Manufacturing, and other industrial applications, helping users identify hazardous gas conditions and maintain safer working environments.

Advanced Multi-Gas Detection

This device detects four critical gases-CH4, O2, CO, and H2S-with rapid 30-second response time. Its electrochemical and catalytic sensors provide accurate readings suited for industrial safety, confined space monitoring, and hazardous environments. The handheld unit delivers real-time alerts to potential dangers, enhancing overall workplace safety.


Rugged, Portable Design

Constructed from durable ABS plastic with a rubberized case, the monitor is built for reliability in harsh environments. Compact (60x130x40mm) and lightweight (230g), it offers ease of use with handheld portability, backlit display, and an IP65 protection rating, suitable for both indoor and outdoor applications.


Efficient Power and Data Management

Equipped with a rechargeable Li-ion battery, this device operates continuously for up to 8 hours and recharges in roughly 4 hours. The optional USB data export enables convenient record-keeping, while the microprocessor controller and automatic/manual calibration ensure ongoing measurement accuracy.

FAQ's of Portable Multi Gas Monitoring Device:


Q: How does the Portable Multi Gas Monitoring Device alert users about dangerous gas levels?

A: When the device detects hazardous concentrations of CH4, O2, CO, or H2S, it triggers alarm signals through sound, flashing lights, and vibration, ensuring prompt user awareness in noisy or low-visibility settings.

Q: What environments and applications is this device suitable for?

A: This monitor is designed for industrial safety, confined space entry, and general gas detection. Its robust construction (IP65 rated) allows it to function effectively in indoor and outdoor environments, even under challenging conditions.

Q: When and how should the gas monitor be calibrated?

A: Calibration, which maintains accuracy, can be performed manually or automatically, depending on user preference. It is recommended to calibrate the device before each use or as required by your facility's safety protocols.

Q: Where is data from gas detection stored, and how can it be exported?

A: Measurement data can be stored internally and, with optional data logging, exported via USB to a computer for analysis, reporting, or record-keeping.

Q: What is the maximum operating time and how long does recharging take?

A: The device delivers up to 8 hours of continuous monitoring on a full charge and typically recharges in approximately 4 hours using its USB port.

Q: How is the device operated and what displays the measured gas readings?

A: The unit is managed with microprocessor control for automatic operation and presents measured values on a clear LCD digital display, including backlighting for low-light conditions.

Q: What are the main benefits of using this portable multi gas monitoring device?

A: Key benefits include rapid, accurate detection of multiple hazardous gases, robust construction for harsh environments, convenient data management, user-friendly operation, and enhanced safety through versatile alarm systems.
